PAD, SEAT 5305670202
1 5305670202
- 5305670202 - PAD
- SEAT
- W/Ref. 3
2 5305670026
- 5305670026 - BOLT
3 5305670201
- 5305670201 - PAD
- BACKREST
- W/Ref. 3
4 1210707011
- 1210707011 - NUT
5 1008707817
- 1008707817 - BOLT
6 5305670101
- 5305670101 - HEADREST
7 5305670203
- 5305670203 - TIE STRAP
8 5305670204
- 5305670204 - ADJUSTABLE RAIL
- W/Ref. 10
9 5305670190
- 5305670190 - HANDLE
10 5305670104
- 5305670104 - WASHER
11 5305670191
- 5305670191 - MOUNTING PARTS
- Ref. 5
- 6
- 11 & 18
12 5305670152
- 5305670152 - BOLT
13 5305670206
- 5305670206 - ROD
14 5305670134
- 5305670134 - RIVET
15 5305670207
- 5305670207 - PLATE
16 5305670208
- 5305670208 - BRACKET
17 5305670200
- 5305670200 - WASHER
18 0190117010
- 0190117010 - WIRE HARNESS
19 5305670223
- 5305670223 - WIRE HARNESS
20 5305670222
- 5305670222 - WIRE HARNESS
21 5305670096
- 5305670096 - SWITCH FLIP
22 5305670220
- 5305670220 - TIE STRAP
23 5305670195
- 5305670195 - LEVER
- W/Ref. 28
- 30 & 38
24 5305670137
- 5305670137 - PLATE
- W/Ref. 26
- 27 & 32
25 5305670138
- 5305670138 - RIVET
26 5305670139
- 5305670139 - SUSPENSION PLATE
27 5305670157
- 5305670157 - BOLT
28 5305670140
- 5305670140 - SLIDING BLOCK
29 5305670156
- 5305670156 - RING
30 5305670141
- 5305670141 - COVER
- W/Ref. 26 & 34
31 5305670032
- 5305670032 - HANDLE
- W/Ref. 33
32 5305670142
- 5305670142 - RIVET
33 5305670209
- 5305670209 - WASHER
34 5305670280
- 5305670280 - COVER
35 5305670143
- 5305670143 - BEARING
36 5305670034
- 5305670034 - SPRING
- W/Ref. 26
- 27 & 32
37 5305670043
- 5305670043 - SPRING
38 5305670155
- 5305670155 - ROD
39 5305670144
- 5305670144 - SEAT PLATE ASSY
- W/Ref. 29 & 66
40 1008707019
- 1008707019 - BOLT
41 1008707318
- 1008707318 - BOLT
42 1212251011
- 1212251011 - NUT
43 5305670035
- 5305670035 - LEVER
44 5305670036
- 5305670036 - HANDLE
45 5305670037
- 5305670037 - ADAPTER PLATE
46 5305670038
- 5305670038 - BOLT
47 5305670154
- 5305670154 - MOUNTING PARTS BACKR
- Includes Ref. 11
- 13
- 36
- 37 & 41-47
48 5305670282
- 5305670282 - COVER
49 5305670145
- 5305670145 - ROCKER CPL
- W/Ref. 3 & 51
50 5305670146
- 5305670146 - SUSPENSION PLATE
- W/Ref. 26
51 5305670040
- 5305670040 - LEVER
- W/Ref. 14-17 & 61-65
52 5305670147
- 5305670147 - COVER
- W/Ref. 3
53 5305670041
- 5305670041 - HANDLE
- W/Ref. 51
54 5305670042
- 5305670042 - HANDLE
55 5305670194
- 5305670194 - BACK REST
- W/Ref. 15
- 63
56 5305670149
- 5305670149 - SLEEVE
57 5305670150
- 5305670150 - BRACKET
58 5305670211
- 5305670211 - BACK SUPPORT ASSY
- W/Ref. 14
- 15 & 61-65
59 1045707512
- 1045707512 - BOLT
60 5305670212
- 5305670212 - HANDLE CPL
- W/Ref. 60
61 5305670213
- 5305670213 - PINION
62 5305670214
- 5305670214 - RIVET
63 5305670215
- 5305670215 - BRAKE
64 5305670216
- 5305670216 - BRACKET
65 5305670153
- 5305670153 - RIVET
