Bobcat
/
442
/
SWIVEL PASS 5383670001 (3)

SWIVEL PASS 5383670001 (3)

SWIVEL PASS 5383670001 (3)

1 5383670001

  • 5383670001 - SWIVEL PASS

2 1008707324

  • 1008707324 - BOLT

3 1290707020

  • 1290707020 - WASHER

4 1212251013

  • 1212251013 - NUT

5 1915060260

  • 1915060260 - FITTING

6 1915060256

  • 1915060256 - FITTING

7 1915060261

  • 1915060261 - FITTING

8 1915060265

  • 1915060265 - FITTING

9 1915060478

  • 1915060478 - FITTING

10 5260310228

  • 5260310228 - SEAL KIT
  • also order shim rings 5383662059 (1) & 5383690004 (1)
