MOTOR, DRIVE HYD 6670817 (1)
1 6670817
- 6670817 - MOTOR
- DRIVE HYD
- W/Ref. 2 - 26
2 6671842
- 6671842 - HOUSING
3 6671830
- 6671830 - ROT GROUP
- rotary group
4 6671853
- 6671853 - BEARN ASY
5 6671852
- 6671852 - GROUP
- ROTARY
- rotary group
6 6671838
- 6671838 - STP SCREW
7 6671843
- 6671843 - PLUG
8 6671844
- 6671844 - O-RING
- W/Ref. 7
9 6671836
- 6671836 - PLUG
10 6671837
- 6671837 - O-RING
- W/Ref. 9
11 6671850
- 6671850 - SHIFT SEAL
12 6671851
- 6671851 - SHIM
13 6671849
- 6671849 - SNAP RING
14 6671839
- 6671839 - NUT
15 6671840
- 6671840 - STP SCREW
16 6690107
- 6690107 - PLUG
- Was 6671832
17 6967789
- 6967789 - THROTTLE SCREW
- throttle - Was 6671833
18 6691476
- 6691476 - PIN
- throttle - Was 6671834
19 6671835
- 6671835 - THR SCREW
- throttle
20 6671841
- 6671841 - VALVE
- SHUTTLE
- check valve
21 6671845
- 6671845 - PLUG
22 6671846
- 6671846 - O-RING
- W/Ref. 21
23 6671848
- 6671848 - VALVE
24 6671847
- 6671847 - O-RING
25 6671867
- 6671867 - LENS CTRL
26 6672018
- 6672018 - SEAL KIT
- W/Ref. 8
- 10
- 16
- 22 & 25 on this page - Ref. 3
- 7
- 10 & 13 on REAR COVER ASSY page - Ref. 4 & 10 on FLUSHING VALVE page
27 6671883
- 6671883 - O-RING
