OIL PUMP 6668279 (1)

OIL PUMP 6668279 (1)

OIL PUMP 6668279 (1)

1 6668279

  • 6668279 - OIL PUMP
  • Oil

2 6670918

  • 6670918 - SHAFT

3 6668280

  • 6668280 - GEAR
  • IDLER
  • Idler - W/Ref. 4
  • 5

4 6667523

  • 6667523 - BUSHING

5 6668281

  • 6668281 - WASHER

6 6514985

  • 6514985 - SNAP RING

7 6668268

  • 6668268 - SCREW

8 6668282

  • 6668282 - VALVE
  • RELIEF
  • Relief - W/Ref. 10-14 & 22

9 6668283

  • 6668283 - PLUNGER

10 6668284

  • 6668284 - SPRING

11 6668285

  • 6668285 - SEAT

12 6668286

  • 6668286 - SNAP RING

13 6668287

  • 6668287 - SCREW

14 907768

  • 907768 - THIMBLE

15 6668288

  • 6668288 - PIPE

16 6668289

  • 6668289 - O-RING

17 6668290

  • 6668290 - FLANGE

18 6668278

  • 6668278 - SCREW

19 6668218

  • 6668218 - VALVE

20 6668523

  • 6668523 - SCREW
