CRANKSHAFT ASSEMBLY 7030327

CRANKSHAFT ASSEMBLY 7030327

CRANKSHAFT ASSEMBLY 7030327

1 7030327

  • 7030327 - CRANKSHAFT ASSEMBLY
  • W/Ref. 2-6

2 7030365

  • 7030365 - KEY
  • WOODRUFF

3 7030346

  • 7030346 - GEAR
  • CRANKSHAFT

4 7030378

  • 7030378 - PIN
  • PARALLEL

5 7030380

  • 7030380 - PIN

6 7030461

  • 7030461 - PULSAR

7 7030460

  • 7030460 - WASHER
  • THRUST
  • set A

8 7370963

  • 7370963 - WASHER THRUST
  • set T

9 7030258

  • 7030258 - BEARING
  • MAIN UPPER BLUE
  • set A - blue

10 7373300

  • 7373300 - BEARING MAIN UPPER
  • set T - yellow

11 7373299

  • 7373299 - BEARING MAIN UPPER
  • set T - red

12 7373301

  • 7373301 - BEARING MAIN UPPER
  • set T - blue

13 7030260

  • 7030260 - BEARING
  • MAIN UPPER YELLOW
  • set A - yellow

14 7030259

  • 7030259 - BEARING
  • MAIN UPPER RED
  • set A - red

15 7373303

  • 7373303 - BEARING MAIN LOWER
  • set T - yellow

16 7373302

  • 7373302 - BEARING MAIN LOWER
  • set T - red

17 7373304

  • 7373304 - BEARING MAIN LOWER
  • set T - blue

18 7030257

  • 7030257 - BEARING
  • MAIN LOWER YELLOW
  • set A - yellow

19 7030256

  • 7030256 - BEARING
  • MAIN LOWER RED
  • set A - red

20 7030255

  • 7030255 - BEARING
  • MAIN LOWER BLUE
  • set A - blue

21 7031363

  • 7031363 - ROD
  • CONNECTING CLASS F

22 7031362

  • 7031362 - ROD
  • CONNECTING CLASS E

23 7031361

  • 7031361 - ROD
  • CONNECTING CLASS D

24 7031359

  • 7031359 - ROD
  • CONNECTING CLASS B

25 7031358

  • 7031358 - ROD
  • CONNECTING CLASS A

26 7031360

  • 7031360 - ROD
  • CONNECTING CLASS C

27 7370946

  • 7370946 - BEARING ENG ROD CONNECTING
  • set T - yellow

28 7370962

  • 7370962 - BEARING ENG ROD CONNECTING
  • set T

29 7030253

  • 7030253 - BEARING
  • ENG ROD CONNECTING
  • set A

30 7370949

  • 7370949 - BEARING ENG ROD CONNECTING
  • set T - yellow

31 7373305

  • 7373305 - BEARING ENG ROD CONNECTING
  • set T

32 7030254

  • 7030254 - BEARING
  • ENG ROD CONNECTING
  • set A

33 7030266

  • 7030266 - BOLT

34 7030395

  • 7030395 - PISTON ENGINE CLASS B

35 7030394

  • 7030394 - PISTON ENGINE CLASS A

36 7030379

  • 7030379 - PIN
  • PISTON ENG

37 7030419

  • 7030419 - RING
  • SNAP

38 7030416

  • 7030416 - RING
  • PISTON

39 7030417

  • 7030417 - RING
  • PISTON

40 7030418

  • 7030418 - RING
  • PISTON

41 7030403

  • 7030403 - PULLEY

42 7030271

  • 7030271 - BOLT

43 7030382

  • 7030382 - PIN

44 7246280

  • 7246280 - COVER
  • DUST
