New Holland Construction
/
(655E) - TRACTOR LOADER BACKHOE (1/96-)
/
SHAFT 85801003

SHAFT 85801003

SHAFT 85801003

1 85801003

  • 85801003 - SHAFT

2 9968409

  • 9968409 - FLANGE

3 71490169

  • 71490169 - SPIDER

4 85801573

  • 85801573 - KIT

5 85804571

  • 85804571 - BOLT
  • Hex
  • M8 x 20mm
  • Cl 10.9

6 11197874

  • 11197874 - BELLEVILLE WASHER
  • M8 Bolt Size x 16mm OD x 2.2mm Thk

7 85801002

  • 85801002 - SHAFT

8 85803545

  • 85803545 - PLATE
