New Holland Construction
/
(B95C) - BACKHOE LOADER - TIER 4B (2/15-)
/
ROOF LINING 87732838

ROOF LINING 87732838

ROOF LINING 87732838

1 87732838

  • 87732838 - ROOF LINING

2 895-15006

  • 895-15006 - WASHER
  • 6.6mm ID x 25mm OD x 1.6mm Thk

3 10902421

  • 10902421 - SCREW
  • Hex
  • M6 x 20mm
  • Cl 8.8

4 87656784

  • 87656784 - BRACKET

5 5162852

  • 5162852 - RIVET
  • 7.3mm OD x 12mm L

6 85805777

  • 85805777 - PLUG
  • Black

7 741346049

  • 741346049 - DIA KIT
  • TLB

8 47944310

  • 47944310 - CONSTRUCTION DIA
