Bobcat
/
751.0
/
PUMP, HYD 7001067REM (1)

PUMP, HYD 7001067REM (1)

PUMP, HYD 7001067REM (1)

1 7001067REM

  • 7001067REM - PUMP
  • HYD
  • Was 6672051REM - does not include gear pump

2 7001070REM

  • 7001070REM - PUMP
  • HYD
  • gray - must use 6576196 bracket & 6706096 bracket from original pump - Was 6671019REM Was 6669464REM

3 6657028

  • 6657028 - O-RING

4 79K8

  • 79K8 - O RING 10

5 6645086

  • 6645086 - PLUG

6 6657067

  • 6657067 - COVER
  • W/Ref. 50

7 6650637

  • 6650637 - BOLT

8 6669405

  • 6669405 - CAP
  • END

9 6650634

  • 6650634 - GASKET

10 6669400

  • 6669400 - VALVE
  • PLATE
  • Model 4355066 & 4355065

11 6650636

  • 6650636 - PIN

12 6650630

  • 6650630 - RETAINER

13 6666339

  • 6666339 - SCREW

14 6650627

  • 6650627 - PLATE THR

15 7284937

  • 7284937 - SWASHPLATE
  • W/threaded shaft hole - Was 6685344

16 6669404

  • 6669404 - SWASHPLATE
  • Model 4355066 & 4355065

17 6671512

  • 6671512 - GROUP
  • ROTARY
  • Model 4445050

18 6661758

  • 6661758 - ROT GROUP
  • Ref. 15 - 25 - Models 4355066 & 4355065

19 6645080

  • 6645080 - O-RING

20 6650677

  • 6650677 - COUPLER
  • Model 4355066 & 4355065

21 6671509

  • 6671509 - COUPLER
  • Model 4445050 - Was 6671519

22 669863

  • 669863 - RING
  • SNAP

23 658128

  • 658128 - RING
  • SNAP

24 654299

  • 654299 - BEARING

25 6652018

  • 6652018 - BOLT

26 6669407

  • 6669407 - SHAFT

27 47K8

  • 47K8 - PLUG
  • W/Ref. 51

28 6650668

  • 6650668 - BOLT

29 6657068

  • 6657068 - COVER

30 6660814

  • 6660814 - RING
  • QUAD

31 6669411

  • 6669411 - BEARING

32 6518460

  • 6518460 - PIN

33 6669403

  • 6669403 - HOUSING

34 6576196

  • 6576196 - BRACKET

35 4CM820

  • 4CM820 - SCREW HEX HD 8.8
  • Was 1CM820

36 6650635

  • 6650635 - BEARING

37 6678226

  • 6678226 - SEAL
  • OIL
  • Was 6650639

38 79K12

  • 79K12 - O RING 10

39 6670684

  • 6670684 - VALVE
  • CHECK

40 6671510

  • 6671510 - VALVE
  • RELIEF
  • Model 4445050

41 6670685

  • 6670685 - VALVE
  • RELIEF
  • Models 4355066 & 4355065 - Was 6689601

42 7001070

  • 7001070 - PUMP
  • HYD TANDEM W/O GEAR PUMP

43 6671516

  • 6671516 - KIT
  • SEAL
  • - Ref. 7
  • 9
  • 13
  • 34
  • 35
  • 42
  • 43
  • 45 & 46 - Also includes Ref. 2
  • 3
  • 12 & 41 on this page - pump Model 4445050 - Was 7296604

44 6658092

  • 6658092 - SEAL KIT
  • Ref. 2
  • 3
  • 12 & 41 - ALSO INCLUDES 7
  • 9
  • 13
  • 34
  • 35
  • 42
  • 43
  • 45 & 46 FOR PUMP MODELS 4355066 & 4355065

45 7339370

  • 7339370 - KIT GUIDE
  • W/Ref. (4) of 21 & 22
