New Holland Construction
/
(655E) - TRACTOR LOADER BACKHOE (1/96-)
/
RESERVOIR, WINDSHIEL 85802057

RESERVOIR, WINDSHIEL 85802057

RESERVOIR, WINDSHIEL 85802057

1 85802057

  • 85802057 - RESERVOIR
  • WINDSHIEL

2 85802058

  • 85802058 - BRACKET

3 79105220

  • 79105220 - SCREW
  • Phillips Drive
  • Oval HD
  • M6 x 20mm

4 85802398

  • 85802398 - NOZZLE

5 12646704

  • 12646704 - WASHER
  • 8.15mm ID x 20mm OD x 2mm Thk

6 16102411

  • 16102411 - THIN NUT
  • Thin
  • M8 x 1
  • Cl 04

7 85802148

  • 85802148 - 3 WAY CONNECTION

8 19052983

  • 19052983 - HOSE
