New Holland Construction
/
(655E) - TRACTOR LOADER BACKHOE (1/96-)
/
WIRE HARNESS 85802589

WIRE HARNESS 85802589

WIRE HARNESS 85802589

1 85802589

  • 85802589 - WIRE HARNESS

2 85805382

  • 85805382 - WIRE HARNESS

3 85815522

  • 85815522 - WIRE HARNESS

4 85802302

  • 85802302 - WIRE CONNECTOR

5 85802303

  • 85802303 - WIRE CONNECTOR

6 85802591

  • 85802591 - WIRE HARNESS

7 85802160

  • 85802160 - WARNING LIGHT

8 14143990

  • 14143990 - BULB
  • 12V
  • 3W

9 13272214

  • 13272214 - SCREW
  • Pozidriv Pan Hd
  • M4 x 16mm
  • Cl 5.8
  • Full Thd

10 15641307

  • 15641307 - SCREW
  • Pozidriv Pan Hd
  • M2.9 x 16mm

11 85805383

  • 85805383 - CABLE TIE

12 85801522

  • 85801522 - IGNITION SWITCH

13 85804674

  • 85804674 - IGNITION SWITCH
  • 10 Pins

14 71451203

  • 71451203 - IGNITION KEY

15 85804675

  • 85804675 - IGNITION KEY

16 85807866

  • 85807866 - CONVERSION KIT

17 784122

  • 784122 - PLUG

18 10427200

  • 10427200 - RIVET
  • Flat Hd
  • M4 x 5

19 85805888

  • 85805888 - LOCKING PLATE

20 85807855

  • 85807855 - WIRE HARNESS

21 10450090

  • 10450090 - CLAMP
  • 8mm
  • Coat
  • 9mm Bolt Hole
  • P Type
