Bobcat
/
Backhoe
/
SLIDE LWR 6660148

SLIDE LWR 6660148

SLIDE LWR 6660148

1 6660148

  • 6660148 - SLIDE LWR

2 6500774

  • 6500774 - SEAT
  • will fit both seat mounts

3 6532792

  • 6532792 - MOUNT
  • 9-1/2" x 9-1/2" mounting plate

4 6511880

  • 6511880 - PIN

5 7D6

  • 7D6 - NUT

6 84G3712

  • 84G3712 - SCREW THD ROLLING TT

7 14J3740

  • 14J3740 - PIN

8 6558680

  • 6558680 - SPACER

9 17C516

  • 17C516 - BOLT
  • Use with 6500774 seat

10 85D5

  • 85D5 - NUT PRETRQ HEX LOCK
  • Use with 6653421 seat

11 6592836

  • 6592836 - PIN

12 6610082

  • 6610082 - SPRING

13 25E15

  • 25E15 - WASHER FLAT PLAIN

14 301939

  • 301939 - PIN

15 6631038

  • 6631038 - PIN
  • SNAP
  • W/chain

16 22J24

  • 22J24 - RING
  • SNAP
  • Was 6538285

17 6584872

  • 6584872 - WASHER 5

18 6560349

  • 6560349 - PIN

19 12H15

  • 12H15 - FTG GREASE 90

20 10H25

  • 10H25 - FTG GREASE STRAIGHT

21 14J3724

  • 14J3724 - PIN

22 6593949

  • 6593949 - BUSHING

23 6594150

  • 6594150 - STABLIZER
  • Was 6593898

24 85D8

  • 85D8 - NUT PRETRQ HEX LOCK

25 6593909

  • 6593909 - PAD
  • STABL

26 37C820

  • 37C820 - BOLT SQ NECK RND HD
  • Was 6560578

27 6593908

  • 6593908 - PIN

28 6560352

  • 6560352 - PIN

29 31C1228

  • 31C1228 - BOLT

30 6593892

  • 6593892 - WASHER

31 225683

  • 225683 - RACE

32 6511242

  • 6511242 - BEARING

33 6531530

  • 6531530 - FRAME
  • SWING
  • swing - W/Ref. 32 - Was 6593874

34 6593893

  • 6593893 - SHAFT

35 6583862

  • 6583862 - DECAL
  • WARNING

36 6593804

  • 6593804 - DECAL
  • mounting instructions

37 6727324

  • 6727324 - DECAL
  • LOGO BOBCAT AND HEAD
  • Was 6714353

38 6632445

  • 6632445 - PAD
  • STREET ASSY
  • street

39 25E21

  • 25E21 - WASHER FLAT PLAIN

40 6560876

  • 6560876 - TUBE
  • handrail - weld on
