VALVE 6655020 (3)
1 6655020
- 6655020 - VALVE
2 79K12
- 79K12 - O RING 10
- Use with flush face couplers
3 79K10
- 79K10 - O RING 10
- Use with poppet couplers
4 15K7
- 15K7 - FITTING
- W/Ref. 2 - used with poppet couplers
5 15KB1012
- 15KB1012 - FTG HYD S CONNECTOR
- W/Ref. 2 - used with flush face couplers - Was 755055B
6 6519195
- 6519195 - ELBOW
- W/Ref. 2
7 17K7
- 17K7 - ELBOW
- W/Ref. 2
8 672554
- 672554 - HYD HOSE
9 6598758
- 6598758 - COUPLER FF FEMALE
- straight
10 7246790
- 7246790 - COUPLER FF FEM 1/2
- - straight - Was 6672960
11 7246790EF
- 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD
12 48K16
- 48K16 - O RING 10
- Use with poppet coupler
13 6598757
- 6598757 - COUPLER
- POPPET MALE
- straight
14 7246777
- 7246777 - COUPLER
- FF MALE
- - straight - Was 6674688
15 7246777EF
- 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE
16 6592821
- 6592821 - TUBE
17 6592816
- 6592816 - TUBE
18 6592824
- 6592824 - ORIFICE
- 2
- 74 mm (0.108") dia.
19 79K8
- 79K8 - O RING 10
20 15K6
- 15K6 - ADAPTER
- W/Ref. 12
21 6592820
- 6592820 - TUBE
22 6592815
- 6592815 - TUBE
23 6562128
- 6562128 - HOSE
24 17K6
- 17K6 - ELBOW
- W/Ref. 12
25 18K6
- 18K6 - FITTING
- W/Ref. 12
26 6561999
- 6561999 - TUBE ASSEMBLY
27 85D5
- 85D5 - NUT PRETRQ HEX LOCK
28 6561995
- 6561995 - CLAMP
29 17C520
- 17C520 - BOLT 5
30 6592813
- 6592813 - TUBE
31 6560428
- 6560428 - RETAINER
32 27E8
- 27E8 - WASHER 10
33 17C840
- 17C840 - BOLT
34 6592823
- 6592823 - TUBE
35 6562505
- 6562505 - WEAR BAR
- wear
36 6562504
- 6562504 - PLATE
37 6562524
- 6562524 - SHIM
38 25E15
- 25E15 - WASHER FLAT PLAIN
39 17C514
- 17C514 - BOLT
40 79K10
- 79K10 - O RING 10
