New Holland Construction
/
(655E) - TRACTOR LOADER BACKHOE (1/96-)
/
TUBE 85803113

TUBE 85803113

TUBE 85803113

1 85803113

  • 85803113 - TUBE
  • 655E
  • 675E

2 85803112

  • 85803112 - HYD TUBE
  • 655E
  • 675E

3 16043624

  • 16043624 - SCREW
  • Hex
  • M8 x 1.25 x 25mm
  • Cl 8.8
  • Full Thd

4 11193974

  • 11193974 - BELLEVILLE WASHER
  • M8 Bolt Size x 22mm OD x 1.5mm Thk

5 14048221

  • 14048221 - NUT
  • M8 x 1.25
  • Cl 10

6 16044131

  • 16044131 - BOLT
  • Hex
  • M8 x 45mm
  • Cl 10.9

7 85803088

  • 85803088 - CLAMP
  • 8 mm Radius and 11.5 mm Radius Holes

8 85802534

  • 85802534 - CLAMP
  • 10 mm Radius and 10 mm Radius Holes

9 85803289

  • 85803289 - PLATE

10 85812165

  • 85812165 - FLEXIBLE HOSE
  • 15.88mm ID x 1350mm L
  • 655E
  • 675E

11 85812190

  • 85812190 - FLEXIBLE HOSE
  • 12.7mm ID x 1350mm L
  • 655E
  • 675E

12 9992069

  • 9992069 - O-RING
  • 0.07" Thk x 0.614" ID
  • -16
  • Cl 6
  • 90 Duro

13 9991976

  • 9991976 - O-RING
  • 0.07" Thk x 0.739" ID
  • -18
  • Cl 6
  • 90 Duro

14 85800911

  • 85800911 - HYDRAULIC CYLINDER
  • Assy
  • Bucket

15 87315527R

  • 87315527R - REMAN-HYD CYLINDER
  • 655E
  • 675E
  • Both TRACTOR LOADER BACKHOE (1/96-)
  • Reman for New PN 85800911

16 87315527C

  • 87315527C - CORE-HYD CYLINDER
  • Return Number
