UNDERCARRIAGE 6190001005 (2)

UNDERCARRIAGE 6190001005 (2)

UNDERCARRIAGE 6190001005 (2)

1 6190001005

  • 6190001005 - UNDERCARRIAGE

2 0190315002

  • 0190315002 - SUPPORT BLADE

3 0190319002

  • 0190319002 - SUPPORT BLADE
  • 2480mm

4 0190002030

  • 0190002030 - SUPPORT BLADE
  • 2330mm - Was 6190002030

5 0205209020

  • 0205209020 - PIN
  • Was 6205209020

6 0205209021

  • 0205209021 - PIN
  • Was 6205209021

7 1045707631

  • 1045707631 - BOLT

8 1212251014

  • 1212251014 - NUT

9 0194019227

  • 0194019227 - WASHER

10 0194019025

  • 0194019025 - WASHER

11 0194002226

  • 0194002226 - WASHER

12 1608003010

  • 1608003010 - FITTING
  • GREASE

13 1309412434

  • 1309412434 - SHIM

14 1309412425

  • 1309412425 - SHIM

15 1008707018

  • 1008707018 - BOLT

16 1343707057

  • 1343707057 - WASHER

17 6190002011

  • 6190002011 - COVER

18 6189602020

  • 6189602020 - COVER RUNNING WHEE

19 6190002010

  • 6190002010 - COVER

20 1290707018

  • 1290707018 - WASHER

21 0190002055

  • 0190002055 - SHIELD
  • Left - Was 6190002055

22 0190002051

  • 0190002051 - PROTECTION
  • Right - Was 6190002051

23 0110012050

  • 0110012050 - RUBBER LAYER

24 5660095400

  • 5660095400 - HOSE CLIP

25 1290707022

  • 1290707022 - WASHER
