SCREW 6588165
1 6588165
- 6588165 - SCREW
- Was 73G000410B
2 22E4
- 22E4 - WASHER
3 6592123
- 6592123 - RETAINER
- Stamped
4 6666582
- 6666582 - SPOOL BOM
- lift - #1 or red - SEE NOTE
5 6666583
- 6666583 - SPOOL BOM
- lift - #2 or green - SEE NOTE
6 6666584
- 6666584 - SPOOL BOM
- lift - #3 or black - SEE NOTE
7 6666585
- 6666585 - SPOOL
- TILT
- tilt - #1 or red - SEE NOTE
8 6666586
- 6666586 - SPOOL
- TILT
- tilt - #2 or green - SEE NOTE
9 6666587
- 6666587 - SPOOL
- TILT
- tilt - #3 or black - SEE NOTE
10 6592119
- 6592119 - SPOOL
- auxiliary - SEE NOTE
11 6592115
- 6592115 - SEAT
12 6592117
- 6592117 - SPRING
- LOAD CHECK
13 79K8
- 79K8 - O RING 10
14 6592116
- 6592116 - NUT
- load check
15 6593680
- 6593680 - RETAINER
16 6676195
- 6676195 - VALVE
- RELIEF
- main relief
17 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check - W/Ref. 23-25 - SEE NOTE - Was 6661345
18 79K10
- 79K10 - O RING 10
19 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
20 58K014
- 58K014 - O-RING 10
- back-up washer required - Was 25K20016
21 6677106
- 6677106 - O-RING
- Back-up Washer Not Required
22 6588163
- 6588163 - SCREW
- 7/8" long - Was 69G000412B
23 29G416
- 29G416 - BOLT
- 1" long - Was 6580982
24 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- W/.50" flange - Was 6587633
25 6592109
- 6592109 - ADAPTER
26 6592100
- 6592100 - COLLAR
27 6587580
- 6587580 - SPRING
- Was 6592106
28 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
29 799119
- 799119 - RING
30 6592098
- 6592098 - WASHER
31 6589226
- 6589226 - COVER
- END
- 0.63" flange
32 6592096
- 6592096 - SLEEVE
- lift
33 6587575
- 6587575 - ADAPTER
- Was 6592099
34 6592107
- 6592107 - SPRING
- DETENT 5
35 6592105
- 6592105 - BALL 5
36 6586918
- 6586918 - SCREW
- DETENT
- Was 6632374
37 6596807
- 6596807 - PLUG
- plastic - 0.46" long
38 54K20002
- 54K20002 - O'RING 10
39 6593349
- 6593349 - SLEEVE
- auxiliary
40 6592720
- 6592720 - PLUG
- W/Ref. 23-25
41 6587763
- 6587763 - BOOT
- Remove Ref. 6 when installing - Was 6583727
42 6665089
- 6665089 - SEAL 5
- lip seal - Was 6659554
43 6646372
- 6646372 - SEAL
- QUAD RING
- quad ring seal
44 6592103
- 6592103 - BUSHING
- See Service Letter 5 Jan. 87
45 6538466
- 6538466 - BUSHING
- W/Part Number stamped on face
46 6587304
- 6587304 - ORIFICE
- .125
47 6587315
- 6587315 - RESTRICTR
- .110
48 6662848
- 6662848 - CAP
- Use W/6587633 Bonnet
49 6588164
- 6588164 - SCREW
50 6660644
- 6660644 - CAP
51 47K7
- 47K7 - PLUG
- .875-14 - W/Ref. 23
52 47K9
- 47K9 - PLUG
- 1.1875-12 - W/Ref. 56
53 79K14
- 79K14 - O RING 10
54 6816250
- 6816250 - KIT
- SEAL
- - Ref. 2
- 26
- 41
- 45 & 46 - one spool - Was 6803605
55 6661328
- 6661328 - SEAL KIT
- Ref. 17 - 20 - Was 6592474
56 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 23-25 - Was 6586461
57 6816251
- 6816251 - KIT
- SEAL
- - Ref. 13
- 17-20
- 23-25
- 41
- 45 & 46 - Was 6803606
