Bobcat
/
540
/
SCREW 85G1014

SCREW 85G1014

SCREW 85G1014

1 85G1014

  • 85G1014 - SCREW

2 6705735

  • 6705735 - WINDOW TOP CAB
  • top - Use W/Ref. 37

3 6701986

  • 6701986 - WINDOW
  • TOP
  • top - not Use W/Ref. 37 - Was 6563391

4 6703159

  • 6703159 - TRACK WINDOW
  • RH - Was 6630921

5 6703160

  • 6703160 - TRACK WINDOW
  • LH - Was 6630920

6 35C410

  • 35C410 - SCREW HEX HD W/F GR5
  • Was 25G000410B

7 6630918

  • 6630918 - BRACKET
  • L.H.

8 6630919

  • 6630919 - TRACK
  • R.H.

9 83D4

  • 83D4 - LKNUT HEX FLG GR8

10 6630924

  • 6630924 - BRACKET

11 6658143

  • 6658143 - WINDOW
  • LH - W/felt - Was 6630922

12 6658142

  • 6658142 - WINDOW
  • RH - W/felt - Was 6630923

13 6702731

  • 6702731 - WINDOW CAB
  • Was 6567750

14 6631548

  • 6631548 - LOOP SCOTCHMATE
  • scotchmate

15 6631549

  • 6631549 - HOOK SCOTCHMATE
  • scotchmate

16 6661689

  • 6661689 - TRACK WINDOW
  • LH - Was 6630916

17 6661690

  • 6661690 - TRACK WINDOW
  • RH - Was 6630917

18 6513152

  • 6513152 - SEAL
  • BULK/FT 25
  • bulk - sold per foot

19 59D4

  • 59D4 - NUT LOCK HEX PT

20 50D10

  • 50D10 - LOCKNUT

21 84G3112

  • 84G3112 - SCREW THD ROLLING TT

22 6568540

  • 6568540 - MOUNT W L

23 6576513

  • 6576513 - BOLT
  • Was 6630927

24 6630926

  • 6630926 - HINGE

25 6555351

  • 6555351 - SEAL BULK/FT 15
  • bulk - sold per foot

26 6630925

  • 6630925 - WINDOW

27 6571529

  • 6571529 - KNOB

28 58K109

  • 58K109 - O RING 10

29 6571532

  • 6571532 - BRACKET

30 6571533

  • 6571533 - MOUNT

31 6554149

  • 6554149 - CORD
  • bulk - sold per foot - Also Order Ref. 36 (6731478 exit tag)

32 6659949

  • 6659949 - LATCH

33 6704891

  • 6704891 - WINDOW REAR
  • Was 6703021

34 6658352

  • 6658352 - MOULDING
  • bulk - sold per foot

35 6731478

  • 6731478 - TAG EXIT
  • Was 6559515

36 6664351

  • 6664351 - MOULDING
  • Use W/cab headliner & Ref. 5 (6705735 window)

37 6665012

  • 6665012 - SEAL RUBBER
  • Use W/O cab headliner & Ref. 5 (6705735 window)

38 6566955

  • 6566955 - INSTRUCTIONS
  • rear Window

39 6566957ENUS

  • 6566957ENUS - INSTRUCTIONS
  • side Windows - Was 6566957
