SNAP RING 992753 (1)
1 992753
- 992753 - SNAP RING
- retaining
2 6J808
- 6J808 - KEY
- WOODRUFF
- woodruff
3 6519668
- 6519668 - VALVE
- exhaust
4 6518898
- 6518898 - SPRING
- valve exhaust
5 6518870
- 6518870 - ROTATOR
- exhaust valve
6 6518861
- 6518861 - KEY
- retainer
7 6518872
- 6518872 - INSERT
- exhaust valve
8 6J404
- 6J404 - KEY
- WOODRUFF
9 6517232
- 6517232 - PLUG
10 6512183
- 6512183 - BEARING
- camshaft - Front
11 6518882
- 6518882 - GUIDE
- VALVE
- valve
12 6518883
- 6518883 - SEAT
- valve spring
13 5J605
- 5J605 - KEY
14 659065
- 659065 - RING
- retaining
15 6513701
- 6513701 - BEARING
- .010
16 6513702
- 6513702 - BEARING
- .020
17 6599730
- 6599730 - FLYWHEEL
- W/Ring Gear
18 7D16
- 7D16 - NUT
19 6513570
- 6513570 - ROD
- connecting (Std.)
20 6513571
- 6513571 - ROD
- connecting (.010)
21 6513949
- 6513949 - RETAINER
- piston pin
22 6632360
- 6632360 - P AND R ASSY
- W/Ring Assy. & Ref. 29 & 31 (Std)
23 6632361
- 6632361 - P AND R ASSY
- W/Ring Assy. & Ref. 29 & 31 (.003)
24 6632362
- 6632362 - P AND R ASSY
- W/Ring Assy. & Ref. 29 & 31 (.010)
25 6632363
- 6632363 - P AND R ASSY
- W/Ring Assy. & Ref. 29 & 31 (.020)
26 6632364
- 6632364 - P AND R ASSY
- W/Ring Assy. & Ref. 29 & 31 (.030)
27 4E6
- 4E6 - WASHER
- lock
28 890414
- 890414 - WASHER
- flat
29 6512175
- 6512175 - RETAINER
- valve spring
30 6512176
- 6512176 - VALVE
- RELIEF
- intake
31 6654125
- 6654125 - NUT
32 6661133
- 6661133 - ASSY
- PISTON
- .030 - W/Ref. 39
33 6661129
- 6661129 - PISTONSTD
- std. - W/Ref. 39 - Was 6661229
34 6661130
- 6661130 - ASSY
- PISTON
- .003 - W/Ref. 39
35 6661131
- 6661131 - ASSY
- PISTON
- .010 - W/Ref. 39
36 6661135
- 6661135 - RING SET
- .020
37 6661136
- 6661136 - RING SET
- .030
38 6661134
- 6661134 - RING SET
- .010
39 6661181
- 6661181 - RING SET
- std.
