MAIN FRAME 6589977

MAIN FRAME 6589977

MAIN FRAME 6589977

1 6589977

  • 6589977 - MAIN FRAME
  • W/O Mount Coupler - Ref. 32 - Was 6587259

2 84G3710

  • 84G3710 - SCREW

3 23J16

  • 23J16 - SNAP RING
  • Was 662770B

4 6560668

  • 6560668 - PIN

5 6806441

  • 6806441 - STABILIZER
  • L.H. - Was 6538536

6 6531990

  • 6531990 - CLEAT

7 6806440

  • 6806440 - STABILIZER
  • R.H. - Was 6538538

8 6560669

  • 6560669 - PIN

9 37C820

  • 37C820 - BOLT SQ NECK RND HD
  • Was 6529377

10 55D8

  • 55D8 - NUT

11 6583862

  • 6583862 - DECAL
  • WARNING
  • stabilizers

12 22J16

  • 22J16 - SNAP RING
  • Was 1320431B

13 6533215

  • 6533215 - DECAL
  • WARNING
  • Transport Warning

14 7109473

  • 7109473 - DECAL
  • LOGO BOBCAT AND HEAD
  • Was 6727324

15 31C1028

  • 31C1028 - BOLT 5

16 83D10

  • 83D10 - NUT 5

17 6539094

  • 6539094 - BALL

18 6539017

  • 6539017 - CHANNEL

19 6533086

  • 6533086 - CHANNEL

20 17C816

  • 17C816 - BOLT

21 85D8

  • 85D8 - NUT PRETRQ HEX LOCK

22 17C620

  • 17C620 - BOLT

23 7D6

  • 7D6 - NUT

24 6660164

  • 6660164 - PAD
  • STREET

25 25E22

  • 25E22 - WASHER

26 61D8

  • 61D8 - NUT 5

27 6586727

  • 6586727 - MT W/COUP
  • W/Coupler Assembly

28 31C1064

  • 31C1064 - BOLT

29 83D10

  • 83D10 - NUT 5

30 6587829

  • 6587829 - SHIM

31 6718769AR

  • 6718769AR - KIT
  • TRANSLATION
  • Translation - SEE NOTE

32 6718769BR

  • 6718769BR - KIT
  • TRANSLATION
  • Translation - SEE NOTE

33 6718770AR

  • 6718770AR - KIT
  • DECAL
  • Decal - SEE NOTE

34 6718770BR

  • 6718770BR - KIT
  • DECAL
  • Decal - SEE NOTE

35 6718770JP

  • 6718770JP - KIT
  • DECAL
  • Decal - SEE NOTE
