ORIFICE 6592865 (2)

ORIFICE 6592865 (2)

ORIFICE 6592865 (2)

1 6592865

  • 6592865 - ORIFICE
  • .1375'' (3.49mm) Dia.

2 15KB0808

  • 15KB0808 - FTG HYD S CONNECTOR
  • W/Ref. 4 - flat boss face

3 79K8

  • 79K8 - O RING 10
  • For flat boss face

4 99K8

  • 99K8 - O-RING
  • For tapered boss face

5 18KB0808

  • 18KB0808 - FITTING
  • HYD ELBOW
  • Flat boss face

6 6534349

  • 6534349 - HOSE

7 6536624

  • 6536624 - TUBE

8 6562266

  • 6562266 - CLAMP TUBE

9 6808074

  • 6808074 - HOSE

10 6808073

  • 6808073 - HOSE

11 81D6

  • 81D6 - NUT

12 6537761

  • 6537761 - CLAMP

13 84G3724

  • 84G3724 - SCREW THD ROLLING TT

14 6502426

  • 6502426 - CLAMP

15 30H38

  • 30H38 - CLIP

16 6536622

  • 6536622 - TUBE

17 6808075

  • 6808075 - HOSE

18 17C624

  • 17C624 - BOLT 5

19 6538438

  • 6538438 - HOSE

20 6536609

  • 6536609 - HOSE

21 6536623

  • 6536623 - TUBE

22 6713390

  • 6713390 - HOSE
  • Was 6534348

23 6610510

  • 6610510 - STRAP
  • TIE 10

24 6806322

  • 6806322 - TUBELINE

25 6806327

  • 6806327 - TUBELINE

26 6806325

  • 6806325 - TUBELINE

27 6806326

  • 6806326 - TUBELINE

28 6577696

  • 6577696 - CLAMP
