WASHER 5 6584872 (1)

WASHER 5 6584872 (1)

WASHER 5 6584872 (1)

1 6584872

  • 6584872 - WASHER 5

2 22J24

  • 22J24 - RING
  • SNAP
  • Was 6538285

3 12H15

  • 12H15 - FTG GREASE 90

4 6532518

  • 6532518 - PIN

5 10H25

  • 10H25 - FTG GREASE STRAIGHT

6 6532517

  • 6532517 - PIN

7 6532519

  • 6532519 - WASHER

8 22J20

  • 22J20 - SNAP RING
  • Was 6538287

9 6532568

  • 6532568 - PIN

10 81D6

  • 81D6 - NUT

11 17C648

  • 17C648 - SCREW HEX CAP

12 6532522

  • 6532522 - PIN

13 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

14 6560334

  • 6560334 - BUSHING
  • Press-in

15 7114802

  • 7114802 - LINK
  • Was 6716262

16 6716263

  • 6716263 - LINK
  • Was 6532528

17 6651171

  • 6651171 - BEARING

18 6532491

  • 6532491 - BOOM
  • DIPPER ARM

19 6560401

  • 6560401 - PIN
  • PIVOT BUCKET

20 6560382

  • 6560382 - PIN
  • LOCK

21 6716256

  • 6716256 - ARM W/A
  • Also order (2) of Ref. 30 - if using standard bucket - Was 6532583

22 6716264

  • 6716264 - LINK
  • BUCKET MACHINED
  • Also order (2) of Ref. 30 - if using standard bucket - Was 6537182

23 6808545

  • 6808545 - DECAL
  • Bobcat - R.H. - Was 6557412

24 6808546

  • 6808546 - DECAL
  • Bobcat - L.H. - Was 6557413

25 6538569

  • 6538569 - DECAL
  • 730S

26 6537350

  • 6537350 - PIN

27 6716402

  • 6716402 - SPACER

28 6714921

  • 6714921 - FRAME
  • X-Change

29 6804485

  • 6804485 - PLATE
  • BOLT-ON

30 17C1052

  • 17C1052 - BOLT

31 6806121

  • 6806121 - DECAL
  • Bolt-on X-Change

32 6900862

  • 6900862 - INSTRUCTIONS
