JOYSTICK, LH 7267158 (1)
1 7267158
- 7267158 - JOYSTICK
- LH
- W/Ref. 2-37
2 7276901
- 7276901 - VALVE
- JOYSTICK RH
- W/Ref. 2-37
3 7004671
- 7004671 - PLUG PT 1/8
4 7006852
- 7006852 - PLUG PF3/8
5 7284551
- 7284551 - O-RING
- Was 7007909
6 7007931
- 7007931 - ORING
7 7003716
- 7003716 - SHIM
8 7003837
- 7003837 - SEAT SPRING
9 7003927
- 7003927 - STOP
10 7003743
- 7003743 - SPRING
11 7006819
- 7006819 - SEAL ROD
12 7007913
- 7007913 - O-RING
13 7003840
- 7003840 - ROD PUSH
14 7003819
- 7003819 - PLATE
15 7029288
- 7029288 - PLATE
16 7028733
- 7028733 - BOOT
- RUBBER
- Was 7003750
17 7003749
- 7003749 - COUPLER JOINT ASSY
18 7276049
- 7276049 - SWASHPLATE
19 7003733
- 7003733 - NUT HEX
20 7007800
- 7007800 - NUT M14
21 7006820
- 7006820 - HANDLE ASSY LH
22 7259145
- 7259145 - HANDLE ASSY LH
23 7006821
- 7006821 - HANDLE ASSY RH
24 7003751
- 7003751 - CAP ROUND
25 7003752
- 7003752 - CAP PEANUT
26 7003753
- 7003753 - BAR HANDLE
27 7007417
- 7007417 - BAR HANDLE
28 7007859
- 7007859 - PIN SPRING
29 7006822
- 7006822 - BOOT
30 7003711
- 7003711 - BUSHING
31 7006823
- 7006823 - CONNECTOR ASSEMBLY
32 7007454
- 7007454 - KIT SPOOL PORT 1 AND 3
- Ref. 6-9 & 12 - ports 1 & 3
33 7007455
- 7007455 - KIT SPOOL PORT 2 AND 4
- Ref. 6-7 & 10-12 - ports 2 & 4
34 7267156
- 7267156 - PLUG
- Ref. 14-17 - ports 1 & 3
35 7267155
- 7267155 - PLUG
- Ref. 14-16 & 18
36 7007420
- 7007420 - HANDLE KIT LH
37 7007020
- 7007020 - HANDLE KIT LH
38 7007421
- 7007421 - HANDLE KIT RH
39 7007021
- 7007021 - HANDLE KIT RH
40 7276032
- 7276032 - SPACER
