NUT 6635526 (1)

NUT 6635526 (1)

NUT 6635526 (1)

1 6635526

  • 6635526 - NUT

2 6635557

  • 6635557 - WASHER

3 6634856

  • 6634856 - PULLEY
  • 2.86'' (72
  • 6 mm) O.D.

4 6520554

  • 6520554 - PULLEY
  • 4'' (101
  • 6 mm) O.D.

5 6634950

  • 6634950 - SPACER

6 6634083

  • 6634083 - FAN

7 6649459

  • 6649459 - SPACER
  • Was 899158B

8 1991037

  • 1991037 - BEARING

9 6J405

  • 6J405 - KEY

10 6634399

  • 6634399 - ROTOR

11 6634854

  • 6634854 - STATOR

12 6634868

  • 6634868 - DIODE

13 6634858

  • 6634858 - DIODE

14 6635498

  • 6635498 - NUT

15 6635531

  • 6635531 - WASHER

16 84G1612

  • 84G1612 - SCREW

17 6634952

  • 6634952 - REGULATOR
  • Ref. 23
  • 25
  • 31 & 33

18 45G812

  • 45G812 - SCREW
