SEAT 6591598 (3)

SEAT 6591598 (3)

SEAT 6591598 (3)

1 6591598

  • 6591598 - SEAT
  • Milsco

2 6643253

  • 6643253 - SEAT
  • OPERATOR VINYL
  • Michigan Seat Co.

3 6675074

  • 6675074 - SEATBELT STANDARD
  • W/O spring plates

4 6630207

  • 6630207 - RIVET POP
  • Was 6512797

5 6711908

  • 6711908 - SPNG PLATE
  • Use W/Ref. 2 (NLA/6667875 Seat Belt)

6 6725373

  • 6725373 - SPRING BELT GUIDE
  • Use W/Ref. 2 (6675074 seal belt)

7 85D7

  • 85D7 - NUT PRETRQ HEX LOCK

8 17C716

  • 17C716 - BOLT

9 17C612

  • 17C612 - SCREW HEX CAP

10 774220

  • 774220 - NUT

11 17C512

  • 17C512 - BOLT 5

12 6594284

  • 6594284 - SPRING TENSION

13 6594257

  • 6594257 - BRACKET

14 85D5

  • 85D5 - NUT PRETRQ HEX LOCK

15 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

16 35C608

  • 35C608 - BOLT

17 6568742

  • 6568742 - BUSHING

18 6704453

  • 6704453 - SPRING COMPRESSION

19 6563313

  • 6563313 - RETAINER

20 6563557

  • 6563557 - WASHER

21 17C608

  • 17C608 - BOLT

22 6704562

  • 6704562 - SEAT BAR
  • Was 6564882

23 6702343

  • 6702343 - BLOCK

24 14J2512

  • 14J2512 - PIN 5

25 6704559

  • 6704559 - LINK
  • W/Ref. 22
  • 23 - Was 6704557

26 35C624

  • 35C624 - SCREW FLGD HEX CAP

27 6700170

  • 6700170 - WASHER
  • nylon

28 6559479

  • 6559479 - NUT RETAINING

29 6594298

  • 6594298 - NUT RETAINING

30 872229

  • 872229 - WASHER

31 6704558

  • 6704558 - LINK
  • W/Ref. 22
  • 23 - Was 6704556

32 35C616

  • 35C616 - SCREW FLGD HEX CAP

33 6594297

  • 6594297 - PEDAL
