VALVE ASSY 6807386

VALVE ASSY 6807386

VALVE ASSY 6807386

1 6807386

  • 6807386 - VALVE ASSY
  • W/Ref. 2-17

2 743108

  • 743108 - FITTING
  • W/Ref. 9
  • 10

3 6519195

  • 6519195 - ELBOW
  • W/Ref. 11
  • 12

4 6675942

  • 6675942 - ASSY
  • VALVE

5 15KB0808

  • 15KB0808 - FTG HYD S CONNECTOR
  • W/Ref. 13
  • 14

6 17KB1010

  • 17KB1010 - FTG HYD ELBOW 90
  • W/Ref. 11
  • 15

7 18KB0808

  • 18KB0808 - FITTING
  • HYD ELBOW
  • W/Ref. 13
  • 16

8 24K7

  • 24K7 - PLUG
  • W/Ref. 11
  • 17

9 91F6

  • 91F6 - O-RING

10 79K10

  • 79K10 - O RING 10

11 79K8

  • 79K8 - O RING 10
