UPPER HYDRAULIC PIPING(BASE, MCV TYPE 3)

UPPER HYDRAULIC PIPING(BASE, MCV TYPE 3)

UPPER HYDRAULIC PIPING(BASE, MCV TYPE 3)

1 31NA-11011

  • 31NA-11011 - PIPE WA-SUCTION
  • Поз.: 1

2 31NA-14100

  • 31NA-14100 - PIPE SUB ASSY
  • Поз.: 2

3 31NA-14101

  • 31NA-14101 - PIPE SUB ASSY
  • Поз.: 2

4 31NA-14110

  • 31NA-14110 - PIPE ASSY
  • Поз.: 2-1

5 31NA-14120

  • 31NA-14120 - PIPE ASSY
  • Поз.: 2-2

6 31NB-12060

  • 31NB-12060 - PIPE WA
  • Поз.: 2-3

7 31EH-11160

  • 31EH-11160 - CHECK VALVE ASSY
  • Поз.: 2-4

8 31ND-11120

  • 31ND-11120 - CHECK VALVE ASSY
  • Поз.: 2-4

9 31NB-12520

  • 31NB-12520 - CHECK VALVE ASSY
  • Поз.: 2-5

10 31ND-11130

  • 31ND-11130 - CHECK VALVE ASSY
  • Поз.: 2-5

11 Y172-006004

  • Y172-006004 - O-RING
  • Поз.: 2-6

12 S109-120406

  • S109-120406 - BOLT-SOCKET
  • Поз.: 2-7

13 S109-120906

  • S109-120906 - BOLT-SOCKET
  • Поз.: 2-8

14 31NA-14130

  • 31NA-14130 - PIPE ASSY
  • Поз.: 3

15 31NA-14140

  • 31NA-14140 - PIPE ASSY
  • Поз.: 4

16 31NA-14151

  • 31NA-14151 - PIPE ASSY
  • Поз.: 5

17 31NA-14161

  • 31NA-14161 - HOSE ASSY
  • Поз.: 6

18 31NA-14171

  • 31NA-14171 - HOSE ASSY
  • Поз.: 7

19 31NA-14181

  • 31NA-14181 - HOSE ASSY
  • Поз.: 8

20 31NA-11190

  • 31NA-11190 - BRACKET WA
  • Поз.: 9

21 31NA-14190

  • 31NA-14190 - PLATE
  • Поз.: 10

22 31NB-13070

  • 31NB-13070 - BRACKET
  • Поз.: 11

23 31NA-14200

  • 31NA-14200 - BLOCK
  • Поз.: 12

24 31E7-01750

  • 31E7-01750 - CLAMP ASSY
  • Поз.: 13

25 33NB-12360

  • 33NB-12360 - CLAMP
  • Поз.: 14

26 33NB-12410

  • 33NB-12410 - CLAMP
  • Поз.: 15

27 P173-280108

  • P173-280108 - FLANGE-HYD
  • SPLIT
  • Поз.: 16

28 P174-160105

  • P174-160105 - FLANGE-HYD
  • SPLIT
  • Поз.: 17

29 P174-160115

  • P174-160115 - FLANGE-SPLIT
  • Поз.: 18

30 31EK-11130

  • 31EK-11130 - COUPLING-SCREW
  • Поз.: 19

31 31NB-13080

  • 31NB-13080 - HOSE
  • Поз.: 20

32 31NB-13090

  • 31NB-13090 - HOSE
  • Поз.: 21

33 P760-101035

  • P760-101035 - HOSE-RUBBER
  • Поз.: 22

34 S017-16095D

  • S017-16095D - BOLT-HEX
  • Поз.: 23

35 S037-103026

  • S037-103026 - BOLT-W/WASHER
  • Поз.: 24

36 S037-123526

  • S037-123526 - BOLT-W/WASHER
  • Поз.: 25

37 S070-026163

  • S070-026163 - U-BOLT
  • Поз.: 26

38 S109-100306

  • S109-100306 - BOLT-SOCKET
  • Поз.: 27

39 S109-120306

  • S109-120306 - BOLT-SOCKET
  • Поз.: 28

40 S109-120356

  • S109-120356 - BOLT-SOCKET
  • Поз.: 29

41 S109-16040D

  • S109-16040D - BOLT-SOCKET
  • Поз.: 30

42 S205-10100B

  • S205-10100B - NUT-HEX
  • Поз.: 31

43 S403-10200B

  • S403-10200B - WASHER-PLAIN
  • Поз.: 32

44 S441-160006

  • S441-160006 - WASHER-HARDENED
  • Поз.: 33

45 S572-750006

  • S572-750006 - CLAMP-HOSE WIRE TYPE
  • Поз.: 34

46 31N6-11190

  • 31N6-11190 - CLAMP-HOSE WIRE TYPE
  • Поз.: 35

47 S631-085001

  • S631-085001 - O-RING
  • Поз.: 36

48 Y171-024004

  • Y171-024004 - O-RING
  • Поз.: 37

49 Y172-006004

  • Y172-006004 - O-RING
  • Поз.: 38

50 Y172-010004

  • Y172-010004 - O-RING
  • Поз.: 39
