HARNESS 6565088

HARNESS 6565088

HARNESS 6565088

1 6565088

  • 6565088 - HARNESS
  • engine - for delco alternator

2 6529472

  • 6529472 - HARNESS
  • engine - for motorola alternator

3 6703688

  • 6703688 - HARNESS
  • engine/chassis - with Bosch Solenoids Ref. 37 & motorola alternator

4 6705156

  • 6705156 - HARNESS
  • Engine/chassis - for Mando alternator

5 6565087

  • 6565087 - HARNESS
  • chassis - Use W/6565088 and 6529472

6 6599698

  • 6599698 - CLIP

7 7251584

  • 7251584 - SWITCH
  • TEMP
  • hyd temp - Was 6632633

8 6671062

  • 6671062 - SWITCH
  • PRESS OIL HYD
  • hydro. pressure - Was 6664577

9 6658818

  • 6658818 - SENDER TEMP
  • eng. temp. - threaded connector - Use W/6658817 gauge

10 1DM6

  • 1DM6 - NUT
  • Use W/Delco Alternator - Was 4DM6

11 6E4

  • 6E4 - WASHER 10

12 6565170

  • 6565170 - CABLE
  • neg

13 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

14 84G3712

  • 84G3712 - SCREW THD ROLLING TT

15 6E6

  • 6E6 - WASHER

16 17C618

  • 17C618 - BOLT
  • Was 17C000616B

17 30H42

  • 30H42 - CLAMP

18 25E17

  • 25E17 - WASHER FLAT PLAIN

19 6514559

  • 6514559 - CABLE

20 2356058

  • 2356058 - BOOT

21 59D5

  • 59D5 - NUT LOCK HEX PT

22 25E15

  • 25E15 - WASHER FLAT PLAIN

23 6569203

  • 6569203 - CLAMP BATTERY
  • Was 6563462

24 6514898

  • 6514898 - 6 CAPS
  • tilt-tite

25 6630155

  • 6630155 - CAP
  • gang - Poison

26 6630154

  • 6630154 - CAP
  • gang - Danger

27 7312552

  • 7312552 - BATTERY 650 CCA DRY
  • - Was 6674687

28 6557450

  • 6557450 - CABLE

29 85D4

  • 85D4 - NUT 5

30 31H17

  • 31H17 - CLAMP
  • Was 30H000019B

31 17C410

  • 17C410 - BOLT 10

32 6564401

  • 6564401 - MOUNT

33 6632186

  • 6632186 - SWITCH

34 6610510

  • 6610510 - STRAP
  • TIE 10
  • Was 6591255

35 30H54

  • 30H54 - CLIP

36 6969775

  • 6969775 - SWITCH
  • OIL PRESSURE
  • Oil pressure - Was 6652576

37 31H42

  • 31H42 - CLIP

38 3675725

  • 3675725 - DIODE

39 6599360

  • 6599360 - SEALANT
  • ELEC .3 OZ
  • electrical - tube - 3 oz

40 6651975

  • 6651975 - SWITCH
  • RELAY MAGNETIC
