HARNESS 6715961
1 6715961
- 6715961 - HARNESS
- engine
2 6664828
- 6664828 - SOCKET
3 6664041
- 6664041 - PIN 10
4 6664585
- 6664585 - CONNECTOR
- Also Order Ref. 2 & 3
5 6658818
- 6658818 - SENDER TEMP
- eng temp - threaded connector
6 19F4
- 19F4 - BUSHING
7 35C512
- 35C512 - SCREW FLGD HEX CAP
8 6657267
- 6657267 - SWITCH
- hydro. press.
9 7297324
- 7297324 - SENSOR
- FUEL
- fuel - W/Ref. 67 - Was 7216514
10 7297326
- 7297326 - SENSOR
- FUEL
- fuel - W/Ref. 67 - Was 7216516
11 6715000
- 6715000 - HARNESS
- WIRE
- cold start
12 7251584
- 7251584 - SWITCH
- TEMP
- hyd temp - 230 degrees - Was 6632633
13 6665358
- 6665358 - COVER
- FUSE
14 84G3712
- 84G3712 - SCREW THD ROLLING TT
15 27E5
- 27E5 - WASHER
16 6672321
- 6672321 - SWITCH
- switch - temp. Sensor/Cold Start
17 30H60
- 30H60 - CLIP INSULATED
18 6668818
- 6668818 - FILTER ASSEMBLY
19 6668819
- 6668819 - FILTER
- OIL HYD
- hydrostatic - 241
- 3 mm (9.5") long
20 6670312
- 6670312 - SWITCH
- MAGNETIC
- starter relay
21 95D5
- 95D5 - NUT
22 10C412
- 10C412 - BOLT
23 6708437
- 6708437 - SPRG CLIP
- fuse cover
24 6665411
- 6665411 - WEDGE
- red
25 6665369
- 6665369 - MOUNT
- FUSE
- fuse
26 6665357
- 6665357 - 2ND LOCK
- yellow
27 6665356
- 6665356 - FUSEBLOCK
- fuse - W/green square seal
28 6650107
- 6650107 - SEAL
29 6707620
- 6707620 - FUSE
- 10A MINI 5
30 6707621
- 6707621 - FUSE
- 15A MINI 5
31 6707623
- 6707623 - FUSE
- 25A MINI 5
32 6674099
- 6674099 - BREAKER
- 25A
33 6631010
- 6631010 - SWITCH
- PRESS OIL ENG
- eng. oil press.
34 6576280
- 6576280 - BOLT BENT
35 6569203
- 6569203 - CLAMP BATTERY
36 59D5
- 59D5 - NUT LOCK HEX PT
37 7312553
- 7312553 - BATTERY 1000 CCA DRY
- - Was 6665427
38 7269857
- 7269857 - BATTERY WET 1000 CCA
39 6715338
- 6715338 - CABLE
- NEGATIVE
- negative
40 6715374
- 6715374 - CABLE
- POSITIVE
- less conduit - positive
41 6666628
- 6666628 - NUT
42 6560172
- 6560172 - COVER
43 6712536
- 6712536 - BATTRYPAN
- battery
44 6555455
- 6555455 - WASHER
45 6597595
- 6597595 - BRACKET
46 1CM1020
- 1CM1020 - SCREW HEX CAP
47 61D4
- 61D4 - NUT 5
48 6800809
- 6800809 - BRACKET
49 6563025
- 6563025 - CABLE
- negative - 22'' (558.80) long
50 6665527
- 6665527 - TIE
- never modify
51 97D6
- 97D6 - NUT 10
52 30H35
- 30H35 - CLIP INSULATED
53 6708278
- 6708278 - HARNESS
- light
54 97D5
- 97D5 - NUT FLGD HEX LOCK
55 6715197
- 6715197 - CLAMP
56 84G3716
- 84G3716 - SCREW THD ROLLING TT
57 6E6
- 6E6 - WASHER
58 17C540
- 17C540 - BOLT
59 6715132
- 6715132 - RETAINER
60 30H50
- 30H50 - CLAMP
61 6715307
- 6715307 - BRACKET
62 6563505
- 6563505 - CONDUIT
- bulk - sold per foot
63 898731
- 898731 - LAMP
64 6705980
- 6705980 - MOUNT
65 6661353
- 6661353 - LIGHT
- HOUSING ASSY
- worklight - W/Ref. 60
66 6665431
- 6665431 - SOCKET AY
- threaded bulb
67 6703796
- 6703796 - MOUNT
- light
68 6707789
- 6707789 - LIGHT ASSEMBLY
69 6666568
- 6666568 - BULB
- 21W
70 6667887
- 6667887 - BULB
- 21/5W
71 6668007
- 6668007 - SCREW
72 6668010
- 6668010 - LENS
73 6599652
- 6599652 - BOOT
74 2356058
- 2356058 - BOOT
75 79K14
- 79K14 - O RING 10
76 6717579
- 6717579 - GASKET
