KIT, ELECTRICAL CONTROLS 6712820

KIT, ELECTRICAL CONTROLS 6712820

KIT, ELECTRICAL CONTROLS 6712820

1 6712820

  • 6712820 - KIT
  • ELECTRICAL CONTROLS
  • controls - W/handles - Ref. 2-27

2 6680457

  • 6680457 - HNDL/4 SWITCH PWM
  • R.H. - Was 6675466

3 6680447

  • 6680447 - DECAL
  • Was 6677370

4 6662257

  • 6662257 - PIN

5 6641176

  • 6641176 - SEAL

6 6640691

  • 6640691 - TERMINAL

7 6707976

  • 6707976 - HANDLE ASSEMBLY
  • L.H. - Also Order Ref. 4
  • 5 & 9-11

8 6640690

  • 6640690 - PIN

9 6641180

  • 6641180 - LOCK METRI PACK
  • Use W/ 2-pin connector

10 6640700

  • 6640700 - LOCK METRI PACK
  • 3-pin

11 6641179

  • 6641179 - CONNECTOR METRI PACK
  • 2-pin

12 6640699

  • 6640699 - CONNECTOR METRI PACK
  • 3-pin

13 6664036

  • 6664036 - NUT

14 6641181

  • 6641181 - LOCK
  • 6-pin

15 6641173

  • 6641173 - CONNECTOR
  • 6-pin

16 6641178

  • 6641178 - CONNECTOR METRI PACK
  • 2-pin

17 6664800

  • 6664800 - LOCK SECONDARY
  • 3-pin triangle

18 6664599

  • 6664599 - CONNECTOR 3 PIN
  • 3-pin triangle

19 6711621

  • 6711621 - MOUNT
  • Use W/Ref. 39

20 6610510

  • 6610510 - STRAP
  • TIE 10
  • Was 6627289

21 6664035

  • 6664035 - CAP

22 45G508

  • 45G508 - BOLT

23 50D5

  • 50D5 - NUT

24 84G3712

  • 84G3712 - SCREW THD ROLLING TT

25 6706552

  • 6706552 - HARNESS
  • for grader

26 45G1212

  • 45G1212 - BOLT

27 50D12

  • 50D12 - NUT

28 6664040

  • 6664040 - PIN 5
  • male

29 6664041

  • 6664041 - PIN 10
  • female

30 6670312

  • 6670312 - SWITCH
  • MAGNETIC
  • relay - Use W/Ref. 39

31 6664388

  • 6664388 - DIODE
  • memory

32 6702650

  • 6702650 - MOUNT FUSE

33 6667569

  • 6667569 - CONNECTOR
  • RECEPTACLE
  • Order (14) of Ref. 22 - W/Ref. 41

34 6664037

  • 6664037 - WASHER

35 6706568

  • 6706568 - KIT
  • HANDLE
  • handle - Ref. 3 - 5
  • 9 - 11 & 31

36 6706567

  • 6706567 - KIT
  • HANDLE DLX RH
  • handle - W/Ref. 2
  • 4
  • 5
  • 7
  • 8 & 31

37 6722759

  • 6722759 - INSTRUCTIONS
  • FOR Ref. 3 - 5 & 9 - 11

38 6722758

  • 6722758 - INSTRUCTIONS
  • for control elec. kit

39 30H49

  • 30H49 - CLAMP

40 6709176

  • 6709176 - BRACKET

41 6709177

  • 6709177 - BRACKET

42 17C612

  • 17C612 - SCREW HEX CAP

43 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

44 30H46

  • 30H46 - CLIP

45 6710299

  • 6710299 - HARNESS
  • ATTACHMENT PWM

46 6710300

  • 6710300 - HARNESS

47 6669286

  • 6669286 - CLAMP
  • W/saddles
