KIT, WIPER 6804292

KIT, WIPER 6804292

KIT, WIPER 6804292

1 6804292

  • 6804292 - KIT
  • WIPER
  • Was 6596179

2 6665688

  • 6665688 - BLADE

3 6665602

  • 6665602 - MOTOR

4 6712260

  • 6712260 - HARNESS
  • W/10-pin connector - w/ (2) diodes

5 6708280

  • 6708280 - MOUNT
  • switch

6 6668817

  • 6668817 - SWITCH
  • rocker - Was 6665706

7 7160765

  • 7160765 - NUT
  • Was 6660988

8 35C416

  • 35C416 - BOLT
  • Was 35C000412B

9 6708286

  • 6708286 - MOUNT
  • nozzle

10 6666767

  • 6666767 - NOZZLE
  • Was 6664555

11 17C514

  • 17C514 - BOLT

12 25E15

  • 25E15 - WASHER FLAT PLAIN

13 83D5

  • 83D5 - LKNUT HEX FLG GR8

14 37C616

  • 37C616 - BOLT

15 6595829

  • 6595829 - MOUNT
  • tank

16 6664554

  • 6664554 - PUMP
  • WIPER WASHER

17 6708035

  • 6708035 - TANK

18 6665605

  • 6665605 - CAP

19 6610510

  • 6610510 - STRAP
  • TIE 10

20 6708069

  • 6708069 - BUSHING

21 6640704

  • 6640704 - CLAMP

22 57D6

  • 57D6 - NUT HEX FLNG GR8
  • Was 55D000006B

23 6666766

  • 6666766 - GROMMET

24 6665687

  • 6665687 - ARM
  • WIPER

25 6804293

  • 6804293 - HARNESS
  • tank

26 3675725

  • 3675725 - DIODE

27 6724236

  • 6724236 - INSTRUCTIONS
