BOLT 18C1024 (2)

BOLT 18C1024 (2)

BOLT 18C1024 (2)

1 18C1024

  • 18C1024 - BOLT

2 6563795

  • 6563795 - WASHER AXLE

3 7134079

  • 7134079 - SPROCKET MACH S70
  • Was 6563798

4 6598829

  • 6598829 - SEAL
  • OIL

5 6679105

  • 6679105 - BOLT
  • STUD WHEEL
  • Was 6506362

6 6561152

  • 6561152 - NUT
  • WHEEL 5

7 6592765

  • 6592765 - WASHER
  • recessed - To take up end play

8 6633672

  • 6633672 - BEARING
  • ROLLER
  • W/Race

9 6592942

  • 6592942 - KIT
  • AXLE SEAL
  • AXLE SEAL

10 6J1210

  • 6J1210 - KEY WOODRUFF

11 6706031

  • 6706031 - HUB
  • WHEEL
  • W/Ref. 8 - 7/16" Studs

12 6552871

  • 6552871 - WASHER AXLE

13 18C1228

  • 18C1228 - BOLT

14 6706032

  • 6706032 - SHAFT AXLE

15 6722929

  • 6722929 - KIT
  • AXLE
  • W/Ref. 8 & 13 - 17
