HARNESS 963ENG
1 6719160
- 6719160 - HARNESS 963ENG
- engine
2 6729058
- 6729058 - HARNESS
- MFR
- main frame - engine & controls
3 6664972
- 6664972 - NUT
4 6676172
- 6676172 - WASHER
5 59D4
- 59D4 - NUT LOCK HEX PT
6 6718415
- 6718415 - SENDER
- eng. temp.
7 19F4
- 19F4 - BUSHING
8 35C512
- 35C512 - SCREW FLGD HEX CAP
9 6674316
- 6674316 - SWITCH
- PRESS OIL HYD
- 3-pin molded connector
10 7297326
- 7297326 - SENSOR
- FUEL
- fuel - W/Ref. 71 - Was 7216516
11 6718417
- 6718417 - SENDER
- hydro. temp. - 230 degrees
12 6675154
- 6675154 - HOLDER
- fuse
13 84G3712
- 84G3712 - SCREW THD ROLLING TT
14 27E5
- 27E5 - WASHER
15 6672321
- 6672321 - SWITCH
- temp. sensor/cold start
16 30H60
- 30H60 - CLIP INSULATED
17 6672584
- 6672584 - FILTER ASSEMBLY
18 6668819
- 6668819 - FILTER
- OIL HYD
- hydrostatic - 241
- 3 mm (9.5") long
19 6679820
- 6679820 - SWITCH
- RELAY MAGNETIC
- starter relay - Was 6674376
20 6675155
- 6675155 - FUSE
- 100A
- mega
21 10C412
- 10C412 - BOLT
22 25G410
- 25G410 - SCREW SKT BTN HD CAP
23 6716621
- 6716621 - COVER
- FUSE
- fuse box
24 6718774
- 6718774 - DECAL
- FUSE RELAY
- relay/fuse
25 6731275
- 6731275 - INSULATION
26 6736071
- 6736071 - FUSE COVER KIT
- extreme applications - W/decal & insulation
27 6725302
- 6725302 - GASKET
- fuse cover
28 43C616
- 43C616 - BOLT
- Was 45C000616B
29 6665357
- 6665357 - 2ND LOCK
- yellow
30 6800809
- 6800809 - BRACKET
31 37C616
- 37C616 - BOLT
32 37C620
- 37C620 - BOLT CARRIAGE
33 6674315
- 6674315 - SWITCH
- PRESS OIL ENG
- eng oil pressure
34 6808878
- 6808878 - BENT BOLT
- Was 6576280
35 6569203
- 6569203 - CLAMP BATTERY
36 59D5
- 59D5 - NUT LOCK HEX PT
37 7269857
- 7269857 - BATTERY WET 1000 CCA
38 7312553
- 7312553 - BATTERY 1000 CCA DRY
- - Was 6665427
39 6715338
- 6715338 - CABLE
- NEGATIVE
- negative
40 6806355
- 6806355 - CABLE
- POSITIVE
- less conduit - positive
41 85D6
- 85D6 - NUT PRETRQ HEX LOCK
42 6712536
- 6712536 - BATTRYPAN
- battery
43 6555455
- 6555455 - WASHER
44 1CM1020
- 1CM1020 - SCREW HEX CAP
45 61D4
- 61D4 - NUT 5
46 6563025
- 6563025 - CABLE
- negative - 22'' (558
- 80mm) long
47 6665527
- 6665527 - TIE
- never modify
48 97D6
- 97D6 - NUT 10
49 30H35
- 30H35 - CLIP INSULATED
50 97D5
- 97D5 - NUT FLGD HEX LOCK
51 6715197
- 6715197 - CLAMP
52 84G3716
- 84G3716 - SCREW THD ROLLING TT
53 6E6
- 6E6 - WASHER
54 17C540
- 17C540 - BOLT
55 6715132
- 6715132 - RETAINER
56 30H50
- 30H50 - CLAMP
57 6715307
- 6715307 - BRACKET
58 6665371
- 6665371 - SWITCH
- VACUUM
- condition indicator
59 12D8
- 12D8 - NUT HEX MACH SCREW
60 25E15
- 25E15 - WASHER FLAT PLAIN
61 12D10
- 12D10 - NUT
62 57D6
- 57D6 - NUT HEX FLNG GR8
63 14D10
- 14D10 - NUT HEX MACH SCREW
64 35C616
- 35C616 - SCREW FLGD HEX CAP
65 6678673
- 6678673 - CONTROLLER
- Was 6678068
66 6649481
- 6649481 - LIGHT
- WEDGE BASE
- base lamp
67 6719383
- 6719383 - HARNESS
- controls
68 24F1
- 24F1 - ELBOW
69 6684037
- 6684037 - SENSOR
- SPEED ENG
- rpm - Was 6658260
70 6726504
- 6726504 - BRACKET
71 53D6
- 53D6 - NUT
72 59D6
- 59D6 - NUT LOCK HEX PT
73 6718659
- 6718659 - HOUSING FUSE RELAY
- fuse
74 6654806
- 6654806 - FUSE
- 15A
75 6718034
- 6718034 - FUSE
- 30A
76 6679820
- 6679820 - SWITCH
- RELAY MAGNETIC
- relay switch
77 6702444
- 6702444 - FUSE 25A 5
78 6624289
- 6624289 - STRAP
- TIE
79 79K14
- 79K14 - O RING 10
80 6717579
- 6717579 - GASKET
81 84G3112
- 84G3112 - SCREW THD ROLLING TT
- mount fuse box cover
