TANK, FUEL 6807186 (2)

TANK, FUEL 6807186 (2)

TANK, FUEL 6807186 (2)

1 6807186

  • 6807186 - TANK
  • FUEL
  • 25 gal. - Was 6804575

2 6804576

  • 6804576 - TANK FUEL
  • aux - 10 gal.

3 7120881

  • 7120881 - SCREEN
  • FILLER
  • Was 6569219

4 42HC200

  • 42HC200 - CLAMP
  • Was 5HM00040B

5 42HC200

  • 42HC200 - CLAMP
  • Use with bulk hose

6 6807248

  • 6807248 - HOSE FUEL FILL

7 6701449

  • 6701449 - FLR.TUBE

8 6661114

  • 6661114 - CAP
  • DIESEL 1 PSI
  • green fuel fill

9 6661696

  • 6661696 - CAP
  • FUEL LOCKING
  • locking - code PK510 - W/Ref. 47

10 5HM23

  • 5HM23 - HOSE CLMP CONST TENS

11 6553412

  • 6553412 - ELBOW

12 6805767

  • 6805767 - INSULATION

13 31H46

  • 31H46 - CLAMP

14 6706517

  • 6706517 - SCREW 10

15 6661213

  • 6661213 - RING
  • COMPRESSION
  • Use W/Ref. 25 (NLA hose)

16 6553411

  • 6553411 - BUSHING
  • PRESS FIT 5
  • 0.38" ID

17 6598908

  • 6598908 - ELBOW BARBED

18 42HS04

  • 42HS04 - CLAMP HOSE TYPE M
  • Was 6515575

19 6657734

  • 6657734 - PUMP
  • PRIMER HAND
  • barbed fittings for 6
  • 35 mm (.25") ID hose - barbed fittings for 6
  • 35 mm (.25") ID hose

20 6597183

  • 6597183 - TUBE
  • 90 degress - 2.36" x 2.36"

21 6806202

  • 6806202 - BRACKET FUEL TANK

22 6805849

  • 6805849 - BRACKET FUEL FILL

23 6729855

  • 6729855 - TUBE FUEL LINE
  • 15.12" long - .26 ID x .312 OD

24 84G3712

  • 84G3712 - SCREW THD ROLLING TT

25 5HM58

  • 5HM58 - CLAMP

26 6599645

  • 6599645 - PLUG
  • STEEL

27 79K14

  • 79K14 - O RING 10

28 6717579

  • 6717579 - GASKET

29 6569752

  • 6569752 - HOSE BULK/FT
  • sold per foot

30 7297326

  • 7297326 - SENSOR
  • FUEL
  • fuel - W/Ref. 30 - Was 7216516

31 6577821

  • 6577821 - HOSE
  • BULK
  • sold per foot

32 6807157

  • 6807157 - COVER FUEL TANK
  • Was 6806208

33 6804639

  • 6804639 - TEE FITNG

34 6803062

  • 6803062 - BRACKET

35 6597184

  • 6597184 - FOAM

36 35C816

  • 35C816 - BOLT

37 30H35

  • 30H35 - CLIP INSULATED

38 6577822

  • 6577822 - HOSE BULK
  • sold per foot

39 6803976

  • 6803976 - RUBRSTRIP
  • rubber

40 6667586

  • 6667586 - SEAL
  • BULK
  • bulk - sold per foot

41 6587458

  • 6587458 - KEY CAP FUEL 2
  • code PK010

42 6578172

  • 6578172 - HOSE BULK
  • sold per foot

43 6800223

  • 6800223 - BRACKET
  • fuel fill

44 37C620

  • 37C620 - BOLT CARRIAGE

45 57D6

  • 57D6 - NUT HEX FLNG GR8

46 30H50

  • 30H50 - CLAMP

47 6802748

  • 6802748 - HOSE
  • bulk - 10 foot length
