RETAINER 6589564 (2)
1 6589564
- 6589564 - RETAINER
2 6587763
- 6587763 - BOOT
3 6589565
- 6589565 - SEAL
4 79K6
- 79K6 - O RING 10
- flat boss face
5 99K6
- 99K6 - O-RING
- tapered boss face
6 6666589
- 6666589 - SPOOL BOM
- lift - # 2 or Green-SEE NOTE
7 6666588
- 6666588 - SPOOL BOM
- lift - # 1 or Red - SEE NOTE
8 6666590
- 6666590 - SPOOL BOM
- lift - # 3 or Black - SEE NOTE
9 6666593
- 6666593 - SPOOL
- TILT
- tilt - # 3 or Black - SEE NOTE
10 6666592
- 6666592 - SPOOLTILT
- tilt - # 2 or Green - SEE NOTE
11 6666591
- 6666591 - SPOOL
- TILT
- tilt - # 1 or Red - SEE NOTE
12 7300937
- 7300937 - SPOOL AUX
- auxiliary - SEE NOTE - Was 6588074
13 6592115
- 6592115 - SEAT
- load check
14 6592117
- 6592117 - SPRING
- LOAD CHECK
15 79K8
- 79K8 - O RING 10
16 6592116
- 6592116 - NUT
- load check
17 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check - W/Ref. 16-18
18 79K10
- 79K10 - O RING 10
19 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
20 58K014
- 58K014 - O-RING 10
- back-up washer required
21 6677106
- 6677106 - O-RING
- back-up washer not required
22 6599161
- 6599161 - VALVE
- RELIEF
- port relief - W/Ref. 16-18
23 6595663
- 6595663 - BUSHING
24 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
25 6587580
- 6587580 - SPRING
26 6592100
- 6592100 - COLLAR
27 6596807
- 6596807 - PLUG
- plastic - 0.46" long
28 6586918
- 6586918 - SCREW
- DETENT
29 6587575
- 6587575 - ADAPTER
30 6592107
- 6592107 - SPRING
- DETENT 5
31 6592105
- 6592105 - BALL 5
32 6531270
- 6531270 - SLEEVE
- DETENT
33 6592098
- 6592098 - WASHER
34 799119
- 799119 - RING
35 6589226
- 6589226 - COVER
- END
- 0.63" flange
36 6660644
- 6660644 - CAP
37 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
38 30G416
- 30G416 - BOLT
39 6592109
- 6592109 - ADAPTER
40 6683274
- 6683274 - SEAL
- SPOOL 10
- Was 6665846
41 6588781
- 6588781 - END CAP
- .87" thick
42 58K124
- 58K124 - O RING 10
43 6596332
- 6596332 - SPRING
44 7108780
- 7108780 - SLEEVE
- Was 6595951
45 6592720
- 6592720 - PLUG
- W/Ref. 16-18
46 1K127
- 1K127 - O-RING 10
- Was 93K127
47 6671583
- 6671583 - VALVE
- RELIEF
- W/Ref. 16-18
48 55K204
- 55K204 - O RING 10
49 29G412
- 29G412 - BOLT
50 29G416
- 29G416 - BOLT
- 1" long
51 6662848
- 6662848 - CAP
52 97K6
- 97K6 - O-RING
- flare end
53 6817553
- 6817553 - CROSS
- W/Ref. 6 - flat boss face - W/flared end o-rings - Was 6805241
54 6577690
- 6577690 - TUBELINE
55 6805243
- 6805243 - FITTING ELBOW
- W/Ref. 6 - flat boss face - W/flared end o-rings
56 97K6
- 97K6 - O-RING
- flare end
57 6665084
- 6665084 - VALVE
- SOLENOID
- W/Ref. 58 & 59
58 6666616
- 6666616 - VALVE
- STEM SOLENOID
59 6586459
- 6586459 - SEAL KIT
60 6717706
- 6717706 - COIL
- 10 VOLT
- w/nut - pwm-10 volt - Was 6666547
61 6676566
- 6676566 - NUT
62 6678552
- 6678552 - RELIEF VLV ANTI-CAV
- PORT RELIEF & ANTI-CAV. - W/Ref. 16 - 3500 PSI - USE IN TILT CYLINDER BASE END PORT - Was 6671632
63 6673904
- 6673904 - SEAL KIT
- W/Ref. 16
- 66 & 67
64 6816250
- 6816250 - KIT
- SEAL
- one spool - Ref. 4
- 42
- 48
- 51
- 52 & 64 - Was 6803605
65 6816253
- 6816253 - KIT
- SEAL
- complete - Ref. 4
- 13
- 16-18
- 21-24
- 42
- 44
- 50-52 & 63 - also Order 6816250 seal kit - Was 6809448
66 6632279
- 6632279 - KIT
- SEAL
- main relief - Ref. 21-24
67 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 16 - 18 - Was 6586461
68 6595131
- 6595131 - SPRING
- .72'' OD
69 55K212
- 55K212 - O RING 10
70 54K20002
- 54K20002 - O'RING 10
71 6596569
- 6596569 - SEAT
