RETAINER 6589564 (6)
1 6589564
- 6589564 - RETAINER
2 6587763
- 6587763 - BOOT
3 7202038
- 7202038 - BUSHING
- ALIGNMENT
- Also Order 82K019 alignment O-ring - Was 6805102
4 79K6
- 79K6 - O RING 10
- flat boss face
5 99K6
- 99K6 - O-RING
- tapered boss face
6 6814511
- 6814511 - SPOOL
- LIFT
- Was 6811411
7 6815152
- 6815152 - SPOOL
- TILT
- Was 6811412
8 7300937
- 7300937 - SPOOL AUX
- auxiliary - SEE NOTE - Was 6588074
9 6592115
- 6592115 - SEAT
- load check
10 6592117
- 6592117 - SPRING
- LOAD CHECK
11 79K8
- 79K8 - O RING 10
12 6592116
- 6592116 - NUT
- load check
13 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check - W/Ref. 16-18
14 79K10
- 79K10 - O RING 10
15 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
16 58K014
- 58K014 - O-RING 10
- back-up washer required
17 6677106
- 6677106 - O-RING
- back-up washer not required
18 6678574
- 6678574 - VALVE
- RELIEF
- port relief - W/Ref. 16-18 - Was 6673184
19 6650102
- 6650102 - O-RING
20 6650101
- 6650101 - O-RING
21 24K5
- 24K5 - PLUG
- Was 90KV5 - Was 90KV5
22 95K6
- 95K6 - O'RING
23 6595663
- 6595663 - BUSHING
24 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
25 6587580
- 6587580 - SPRING
26 6592100
- 6592100 - COLLAR
27 6596807
- 6596807 - PLUG
- plastic - 0.46" long
28 6586918
- 6586918 - SCREW
- DETENT
29 6587575
- 6587575 - ADAPTER
30 6592107
- 6592107 - SPRING
- DETENT 5
31 6592105
- 6592105 - BALL 5
32 6531270
- 6531270 - SLEEVE
- DETENT
33 6592098
- 6592098 - WASHER
34 799119
- 799119 - RING
35 6589226
- 6589226 - COVER
- END
- 0.63" flange
36 6660644
- 6660644 - CAP
37 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
38 30G416
- 30G416 - BOLT
39 6592109
- 6592109 - ADAPTER
40 6683274
- 6683274 - SEAL
- SPOOL 10
- spool - Was 6665846
41 6805651
- 6805651 - AUX BLOCK
- aux
42 58K124
- 58K124 - O RING 10
43 6596332
- 6596332 - SPRING
44 7108780
- 7108780 - SLEEVE
- Was 6595951
45 6592720
- 6592720 - PLUG
- W/Ref. 16 - 18
46 1K127
- 1K127 - O-RING 10
- Was 93K127
47 6812815
- 6812815 - ADAPTER
- W/Ref. 6 - Was 6805242
48 55K204
- 55K204 - O RING 10
49 29G444
- 29G444 - BOLT
50 29G416
- 29G416 - BOLT
- 1" long
51 6662848
- 6662848 - CAP
52 6805696
- 6805696 - TEE
- W/Ref. 16 - tapered boss face
53 97K6
- 97K6 - O-RING
- flare end
54 6806496
- 6806496 - TUBELINE
55 6588781
- 6588781 - END CAP
56 6665084
- 6665084 - VALVE
- SOLENOID
- W/Ref. 58 & 59
57 6676249
- 6676249 - STEM
- VALVE SOLENOID
- Was 6666616
58 6679961
- 6679961 - NUT
- coil
59 6586459
- 6586459 - SEAL KIT
60 6717706
- 6717706 - COIL
- 10 VOLT
- pwm - 10 volt - w/nut
61 6676566
- 6676566 - NUT
62 6678552
- 6678552 - RELIEF VLV ANTI-CAV
- port relief & anti-cav.-W/Ref. 16 - 3500 PSI - use in tilt cylinder base end port - Was 6671632
63 6673904
- 6673904 - SEAL KIT
- W/Ref. 16
- 67
- 68
64 6676029
- 6676029 - SOLENOID
- LOCK SPOOL
- 127 mm (5") wire - W/Ref. 13 - 3-pin connector - Order for production valve
65 6595131
- 6595131 - SPRING
- .72'' OD
66 55K212
- 55K212 - O RING 10
67 54K20002
- 54K20002 - O'RING 10
68 6596569
- 6596569 - SEAT
69 6671583
- 6671583 - VALVE
- RELIEF
70 6812031
- 6812031 - SPOOL LOCK BLOCK
- lock - Was 6805657
71 90K8
- 90K8 - PLUG
- W/Ref. 71 - Was 90KV00008B
72 95K12
- 95K12 - O-RING
73 6806561
- 6806561 - PLUG W/SEALS
- W/Ref. 73-74
74 79K7
- 79K7 - O RING 10
75 25K20012
- 25K20012 - O RING 10
- Was 58K000012B
76 6816253
- 6816253 - KIT
- SEAL
- complete - Ref. 2
- 4
- 6
- 13
- 16-18
- 21-24
- 42
- 44
- 48
- 52
- 58
- 61 & 62 - Was 6809448
77 6816252
- 6816252 - SEAL KIT
- two spool - Ref. 4
- 42
- 48
- 51 & 64 - Was 6806941
78 6661328
- 6661328 - SEAL KIT
- main relief - Ref. 21-24
79 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 16-18 - Was 6586461
