RETAINER 6589564 (7)
1 6589564
- 6589564 - RETAINER
2 6587763
- 6587763 - BOOT
3 6589565
- 6589565 - SEAL
4 99K6
- 99K6 - O-RING
- tapered boss face
5 7222716
- 7222716 - SPOOL
- LIFT
- lift - #1 or red - SEE NOTE - Was 6674297
6 7222717
- 7222717 - SPOOL
- LIFT
- lift - #2 or green - SEE NOTE - Was 6674298
7 7222718
- 7222718 - SPOOL
- LIFT
- lift - #3 or black - SEE NOTE - Was 6674299
8 6674302
- 6674302 - SPOOL
- tilt - # 3 or Black - SEE NOTE
9 7300937
- 7300937 - SPOOL AUX
- auxiliary - SEE NOTE - Was 6588074
10 6592115
- 6592115 - SEAT
- load check
11 6592117
- 6592117 - SPRING
- LOAD CHECK
12 79K8
- 79K8 - O RING 10
13 6592116
- 6592116 - NUT
- load check - W/Ref. 13
14 6667549
- 6667549 - VALVE
- CHECK
- anti-cavity check - W/Ref. 16-18
15 79K10
- 79K10 - O RING 10
16 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
17 58K014
- 58K014 - O-RING 10
- back-up washer required
18 6677106
- 6677106 - O-RING
- back-up washer not required
19 6678574
- 6678574 - VALVE
- RELIEF
- port relief - W/Ref. 16 - 18 - Was 6673184
20 6650102
- 6650102 - O-RING
21 6650101
- 6650101 - O-RING
22 24K5
- 24K5 - PLUG
- W/Ref. 65 - Was 90KV5
23 95K6
- 95K6 - O'RING
24 6595663
- 6595663 - BUSHING
25 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
26 6587580
- 6587580 - SPRING
27 6592100
- 6592100 - COLLAR
28 6801167
- 6801167 - SPOOLPLUG
- plastic - 0.69" long
29 95K12
- 95K12 - O-RING
30 90K8
- 90K8 - PLUG
- W/Ref. 30 - socket head - Was 90KV00008B
31 6595131
- 6595131 - SPRING
- .72'' OD
32 6805651
- 6805651 - AUX BLOCK
- aux
33 6679757
- 6679757 - VALVE
- RELIEF
- 4000 psi - Was 6671583
34 6596569
- 6596569 - SEAT
35 54K20002
- 54K20002 - O'RING 10
36 6803092
- 6803092 - BONNET
- .625 flange
37 55K212
- 55K212 - O RING 10
38 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
39 30G416
- 30G416 - BOLT
40 6592109
- 6592109 - ADAPTER
41 6683274
- 6683274 - SEAL
- SPOOL 10
- spool - Was 6665846
42 6588781
- 6588781 - END CAP
- .87" thick
43 58K124
- 58K124 - O RING 10
44 6596332
- 6596332 - SPRING
45 7108780
- 7108780 - SLEEVE
- Was 6595951
46 6592720
- 6592720 - PLUG
- W/Ref. 16-18
47 1K127
- 1K127 - O-RING 10
- Was 93K127
48 6812815
- 6812815 - ADAPTER
- W/Ref. 6 - Was 6805242
49 55K204
- 55K204 - O RING 10
50 29G412
- 29G412 - BOLT
51 29G416
- 29G416 - BOLT
- 1" long
52 6662848
- 6662848 - CAP
53 6805696
- 6805696 - TEE
- W/Ref. 6
54 6806496
- 6806496 - TUBELINE
55 29G436
- 29G436 - BOLT
56 6665084
- 6665084 - VALVE
- SOLENOID
- W/Ref. 8 & 9
57 6676249
- 6676249 - STEM
- VALVE SOLENOID
- Was 6666616
58 6679961
- 6679961 - NUT
- coil
59 6586459
- 6586459 - SEAL KIT
60 6717706
- 6717706 - COIL
- 10 VOLT
- pwm - 10 volt - w/nut
61 6676566
- 6676566 - NUT
62 6678552
- 6678552 - RELIEF VLV ANTI-CAV
- port relief & anti-cav.-W/Ref. 16
- 32
- 33 - 3500 PSI - use in tilt cylinder base end port - Was 6671632
63 6806561
- 6806561 - PLUG W/SEALS
- W/Ref. 67-68
64 79K7
- 79K7 - O RING 10
65 58K012
- 58K012 - O-RING 10
- Was 58K000012B
66 6816253
- 6816253 - KIT
- SEAL
- complete - Ref. 4
- 13
- 16-18
- 21-24
- 38
- 42
- 44
- 50-52 & 70 - also Order 6816250 seal kit - Was 6809448
67 6816250
- 6816250 - KIT
- SEAL
- one spool - Ref. 4
- 36
- 42
- 48
- 51 & 52 - Was 6803605
68 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 16-18 - Was 6586461
