Bobcat
/
963
/
GRIP LEVER 6564452 (2)

GRIP LEVER 6564452 (2)

GRIP LEVER 6564452 (2)

1 6564452

  • 6564452 - GRIP LEVER

2 6705452

  • 6705452 - LEVER

3 35C610

  • 35C610 - BOLT 5

4 6567962

  • 6567962 - WASHER

5 84G3724

  • 84G3724 - SCREW THD ROLLING TT

6 6576262

  • 6576262 - MOUNT

7 6630945

  • 6630945 - WASHER

8 6734416

  • 6734416 - LEVER
  • THROTTLE
  • 3-hole rod attachment

9 85D5

  • 85D5 - NUT PRETRQ HEX LOCK

10 6576261

  • 6576261 - COVER
  • Was 6734520

11 6706572

  • 6706572 - SCREW

12 57D6

  • 57D6 - NUT HEX FLNG GR8

13 6800109

  • 6800109 - ROD
  • throttle

14 6512274

  • 6512274 - CLIP
  • NLA - Was 6512274

15 6557291

  • 6557291 - SWIVEL
  • BALL JOINT

16 85D4

  • 85D4 - NUT 5

17 17C620

  • 17C620 - BOLT

18 55D6

  • 55D6 - NUT

19 83D6

  • 83D6 - LKNUT HEX FLG GR8

20 6800111

  • 6800111 - MOUNT

21 6700170

  • 6700170 - WASHER

22 6567407

  • 6567407 - LEVER
  • throttle

23 6564343

  • 6564343 - TUBE SPACER

24 25E17

  • 25E17 - WASHER FLAT PLAIN

25 35C620

  • 35C620 - BOLT 5

26 6800110

  • 6800110 - ROD
  • throttle

27 8D4

  • 8D4 - NUT

28 6631036

  • 6631036 - BALLJOINT

29 86D4

  • 86D4 - NUT

30 30H23

  • 30H23 - CLAMP

31 6705484

  • 6705484 - BUSHING

32 17C628

  • 17C628 - BOLT
  • Was 35C000624B

33 7300707

  • 7300707 - KIT
  • THROTTLE LEVER
  • (3) of Ref. 4 and 3
  • 7
  • 8
  • 9
