HOSE 6530884 (4)

HOSE 6530884 (4)

HOSE 6530884 (4)

1 6530884

  • 6530884 - HOSE
  • Was 5207800B

2 83F5

  • 83F5 - ELBOW

3 2342026

  • 2342026 - COUPLING
  • female

4 25K30018

  • 25K30018 - O RING 10

5 2341398

  • 2341398 - COUPLER
  • male

6 1631632

  • 1631632 - ELBOW

7 86F5

  • 86F5 - NUT

8 45K5

  • 45K5 - FITTING

9 6563437

  • 6563437 - HOSE

10 17C632

  • 17C632 - BOLT 5

11 27E6

  • 27E6 - WASHER HARDEN PLAIN

12 6557730

  • 6557730 - GRIP

13 6564395

  • 6564395 - LEVER

14 6630081

  • 6630081 - BUSHING

15 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

16 6560677

  • 6560677 - BUSHING

17 17C624

  • 17C624 - BOLT 5

18 6513495

  • 6513495 - PIN 5

19 1319560

  • 1319560 - PIN

20 6560668

  • 6560668 - PIN

21 23J16

  • 23J16 - SNAP RING
  • Was 662770B

22 6567072

  • 6567072 - PIN

23 6703819

  • 6703819 - RETAINER
  • Was 6578760

24 6564692

  • 6564692 - WASHER

25 35C816

  • 35C816 - BOLT

26 14J1214

  • 14J1214 - ROLL PIN

27 61D10

  • 61D10 - NUT

28 6560664

  • 6560664 - TUBE ASSEMBLY

29 17C824

  • 17C824 - BOLT 5

30 85D8

  • 85D8 - NUT PRETRQ HEX LOCK

31 6560678

  • 6560678 - ANGLE

32 22J16

  • 22J16 - SNAP RING
  • Was 1320431B

33 6560669

  • 6560669 - PIN

34 6578759

  • 6578759 - CHANNEL
  • RH
  • R.H. - Was 6567062

35 6578757

  • 6578757 - CHANNEL
  • LH
  • L.H. - Was 6567061

36 6563438

  • 6563438 - HOSE

37 19K5

  • 19K5 - FITTING
  • W/Ref. 39

38 79K6

  • 79K6 - O RING 10

39 3580358

  • 3580358 - FITTING
  • ADAPTER
  • W/Ref. 41

40 79K10

  • 79K10 - O RING 10

41 6513713

  • 6513713 - VALVE

42 17KB1012

  • 17KB1012 - FITTING
  • HYD ELBOW
  • Was 1302104B

43 79K12

  • 79K12 - O RING 10

44 61D6

  • 61D6 - NUT HEX FINISHED GR5

45 17C640

  • 17C640 - BOLT

46 6560680

  • 6560680 - TUBE

47 6560706

  • 6560706 - TUBE
  • 630 & 640 Series

48 6560687

  • 6560687 - TUBE
  • 730 & 740 Series

49 6559571

  • 6559571 - VALVE
  • CHECK
  • check

50 25K20022

  • 25K20022 - O RING 10

51 15K7

  • 15K7 - FITTING
  • W/Ref. 41 - use with tube

52 6560705

  • 6560705 - TUBELINE
  • 630 & 640 Series

53 6560679

  • 6560679 - TUBE
  • NLA - 730 & 740 series only - Was 6560679

54 13K7

  • 13K7 - FITTING

55 1519324

  • 1519324 - PLUG

56 1513549

  • 1513549 - CAP

57 6562627

  • 6562627 - DECAL

58 6632446

  • 6632446 - STREETPAD
  • weld on

59 77F7

  • 77F7 - ELBOW
  • Use with 6577890 hose

60 6567081

  • 6567081 - PLATE
  • weld on

61 6567082

  • 6567082 - BLOCK
  • weld on

62 6577890

  • 6577890 - HOSE

63 17K7

  • 17K7 - ELBOW
  • W/Ref. 41 - use with hose

64 6567726

  • 6567726 - REARAUXKT
  • W/Ref. 4-21
  • 24
  • 26
  • 27
  • 37
  • 38
  • 40-43
  • 45-48
  • 50
  • 51
  • 54-57
  • 59-63 & 65
