ELBOW 6519195 (11)

ELBOW 6519195 (11)

ELBOW 6519195 (11)

1 6519195

  • 6519195 - ELBOW
  • W/Ref. 2

2 79K10

  • 79K10 - O RING 10
  • Use with poppet couplers

3 79K12

  • 79K12 - O RING 10
  • Use with flush face couplers - flat boss face

4 99K12

  • 99K12 - O-RING
  • Use with flush face couplers - tapered boss face

5 6534346

  • 6534346 - HOSE
  • .875" threads on quick coupler end - used with 905 elbows

6 6715168

  • 6715168 - HOSE
  • 1.06" threads on quick coupler end - used with 455 elbows

7 6534347

  • 6534347 - HOSE
  • .875" threads on quick coupler end - used with 905 elbows

8 6715169

  • 6715169 - HOSE
  • 1.06" threads on quick coupler end - used with 455 elbows

9 15K6

  • 15K6 - ADAPTER
  • W/Ref. 15 - flat boss face

10 15KB0808

  • 15KB0808 - FTG HYD S CONNECTOR
  • W/Ref. 15 - flat boss face

11 97K8

  • 97K8 - O-RING
  • flared end

12 17K7

  • 17K7 - ELBOW
  • 90 degrees - W/Ref. 2 - used with poppet couplers - flat boss face

13 17KB1012

  • 17KB1012 - FITTING
  • HYD ELBOW
  • 90 degrees - W/Ref. 2 - used with flush face couplers - flat boss face - Was 1302104B

14 18KB1212

  • 18KB1212 - FITTING
  • HYD ELBOW
  • 45 degrees - W/Ref. 2 - Use W/ flush face couplers - flat boss face

15 97K12

  • 97K12 - O-RING
  • flared end

16 7246790EF

  • 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD

17 6598758

  • 6598758 - COUPLER FF FEMALE
  • straight

18 7246790

  • 7246790 - COUPLER FF FEM 1/2
  • - straight - Was 6672960

19 48K16

  • 48K16 - O RING 10
  • Use with poppet coupler

20 7246777EF

  • 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE

21 7246777

  • 7246777 - COUPLER
  • FF MALE
  • - straight - Was 6674688

22 6598757

  • 6598757 - COUPLER
  • POPPET MALE
  • straight

23 84G3110

  • 84G3110 - SCREW

24 6532860

  • 6532860 - PLATE
  • WEAR

25 6532861

  • 6532861 - SHIM

26 6532859

  • 6532859 - BAR
  • WEAR

27 743108

  • 743108 - FITTING
  • W/Ref. 15

28 79K8

  • 79K8 - O RING 10
  • for flat boss face

29 99K8

  • 99K8 - O-RING
  • for tapered boss face

30 6596802

  • 6596802 - HOSE

31 6533046

  • 6533046 - HOSE

32 6532869

  • 6532869 - PIN

33 6587338

  • 6587338 - ORFICE
  • .090" (2
  • 29mm) dia - 0.42" (10.67mm) O.D.

34 6592853

  • 6592853 - ORIFICE
  • .090" (2
  • 29mm) dia - 0.55" (13
  • 97mm) O.D.

35 7109886

  • 7109886 - ORIFICE
  • .086 dia. x .55" O.D.

36 6528927

  • 6528927 - WASHER

37 6532957

  • 6532957 - TUBE

38 6532959

  • 6532959 - TUBE

39 84G3720

  • 84G3720 - SCREW THD ROLLING TT

40 55D6

  • 55D6 - NUT

41 6596801

  • 6596801 - HOSE

42 79K10

  • 79K10 - O RING 10
