ELBOW 6519195 (7)

ELBOW 6519195 (7)

ELBOW 6519195 (7)

1 6519195

  • 6519195 - ELBOW
  • W/Ref. 2

2 79K10

  • 79K10 - O RING 10
  • Use with poppet couplers

3 79K12

  • 79K12 - O RING 10
  • Use with flush face couplers

4 6534346

  • 6534346 - HOSE

5 6534347

  • 6534347 - HOSE

6 15K6

  • 15K6 - ADAPTER
  • W/Ref. 15 - flat boss face

7 15KB0808

  • 15KB0808 - FTG HYD S CONNECTOR
  • W/Ref. 15 - flat boss face

8 97K8

  • 97K8 - O-RING
  • for flared end

9 17K7

  • 17K7 - ELBOW
  • Use with poppet couplers

10 17KB1012

  • 17KB1012 - FITTING
  • HYD ELBOW
  • Use with flush face couplers - Was 1302104B

11 6598758

  • 6598758 - COUPLER FF FEMALE
  • straight

12 7246790

  • 7246790 - COUPLER FF FEM 1/2
  • - straight - Was 6672960

13 7246790EF

  • 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD

14 48K16

  • 48K16 - O RING 10
  • for poppet coupler

15 6598757

  • 6598757 - COUPLER
  • POPPET MALE
  • straight

16 7246777

  • 7246777 - COUPLER
  • FF MALE
  • - straight - Was 6674688

17 7246777EF

  • 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE

18 84G3110

  • 84G3110 - SCREW

19 6532860

  • 6532860 - PLATE
  • WEAR

20 6532861

  • 6532861 - SHIM

21 6532859

  • 6532859 - BAR
  • WEAR

22 743108

  • 743108 - FITTING
  • W/Ref. 15

23 79K8

  • 79K8 - O RING 10
  • for flat boss face

24 99K8

  • 99K8 - O-RING
  • for tapered boss face

25 6640724

  • 6640724 - HOSE

26 6533046

  • 6533046 - HOSE

27 6532869

  • 6532869 - PIN

28 6587338

  • 6587338 - ORFICE
  • .090" (2
  • 29mm) Dia - 0.42" (10.67mm) O.D.

29 6592853

  • 6592853 - ORIFICE
  • .090" (2
  • 29mm) Dia - 0.55" (13
  • 97mm) O.D.

30 7109886

  • 7109886 - ORIFICE
  • .086" dia x .55" O.D.

31 6528927

  • 6528927 - WASHER

32 6532957

  • 6532957 - TUBE

33 6532959

  • 6532959 - TUBE

34 84G3720

  • 84G3720 - SCREW THD ROLLING TT

35 55D6

  • 55D6 - NUT

36 11K5

  • 11K5 - FITTING
  • ELBOW
  • flat boss face

37 97K6

  • 97K6 - O-RING
  • for flared end

38 77F5

  • 77F5 - FITTING
