BEARING ASSEMBLY 6519337 (2)

BEARING ASSEMBLY 6519337 (2)

BEARING ASSEMBLY 6519337 (2)

1 6519337

  • 6519337 - BEARING ASSEMBLY

2 6592349

  • 6592349 - SHAFT

3 6560416

  • 6560416 - WASHER

4 31C1024

  • 31C1024 - BOLT

5 14J3740

  • 14J3740 - PIN

6 6500774

  • 6500774 - SEAT
  • will fit both seat mounts - Also Order Ref. 34 (6593685 decal)

7 6660148

  • 6660148 - SLIDE LWR

8 6532792

  • 6532792 - MOUNT
  • 9.5" x 9.5" (241
  • 3 mm x 241
  • 3 mm) mounting plate

9 85D5

  • 85D5 - NUT PRETRQ HEX LOCK
  • Use W/6653421

10 17C516

  • 17C516 - BOLT
  • Use W/6500774

11 6561942

  • 6561942 - MNT LH
  • L.H. - W/ball - See Ref. 55

12 31C1028

  • 31C1028 - BOLT 5

13 27E10

  • 27E10 - WASHER

14 6561943

  • 6561943 - MNT RH
  • R.H. - W/Ball - See Ref. 55

15 83D10

  • 83D10 - NUT 5

16 6562482

  • 6562482 - SPACER

17 6561829

  • 6561829 - COVER

18 84G3712

  • 84G3712 - SCREW THD ROLLING TT

19 6562092

  • 6562092 - PIN

20 6593080

  • 6593080 - STAB TUBE
  • stabilizer

21 6562093

  • 6562093 - PIN

22 1315207

  • 1315207 - RING RETAINING

23 85D10

  • 85D10 - NUT
  • 5

24 6563535

  • 6563535 - PAD

25 17C1072

  • 17C1072 - BOLT

26 61D8

  • 61D8 - NUT 5

27 10H25

  • 10H25 - FTG GREASE STRAIGHT

28 6560427

  • 6560427 - RETAINER
  • retainer

29 17C844

  • 17C844 - BOLT

30 6513682

  • 6513682 - RACE

31 6560845

  • 6560845 - ARM
  • SWING
  • swing - W/Ref. 29 & 31

32 6559944

  • 6559944 - GEAR
  • weld on

33 6583862

  • 6583862 - DECAL
  • WARNING
  • Was 6562922

34 6593685

  • 6593685 - DECAL
  • mounting instructions

35 6553976

  • 6553976 - TREAD
  • SAFETY
  • 127 x 203 mm (5 x 8")

36 6557935

  • 6557935 - TREAD
  • SAFETY
  • 4.5" x 4.5" (114
  • 3 mm x 114
  • 3 mm)

37 6539094

  • 6539094 - BALL
  • latch - Was 6561941

38 6562596

  • 6562596 - GUIDE

39 17C812

  • 17C812 - BOLT

40 17C1232

  • 17C1232 - BOLT

41 7D12

  • 7D12 - NUT

42 6562600

  • 6562600 - COUPLER

43 6563534

  • 6563534 - PAD

44 6562241

  • 6562241 - COVER
  • tube

45 6598371

  • 6598371 - CAP

46 6511880

  • 6511880 - PIN

47 6593058

  • 6593058 - GUIDE
  • guide

48 7D6

  • 7D6 - NUT

49 6558680

  • 6558680 - SPACER

50 6610082

  • 6610082 - SPRING

51 6592836

  • 6592836 - PIN

52 301939

  • 301939 - PIN

53 1F308

  • 1F308 - PIN
  • COTTER

54 25E15

  • 25E15 - WASHER FLAT PLAIN

55 6632446

  • 6632446 - STREETPAD
  • weld on

56 6562109

  • 6562109 - STOP
  • SWING

57 17C616

  • 17C616 - BOLT 5
