ELBOW 6519195 (10)

ELBOW 6519195 (10)

ELBOW 6519195 (10)

1 6519195

  • 6519195 - ELBOW
  • W/Ref. 2

2 79K12

  • 79K12 - O RING 10
  • Use with flush face couplers

3 79K10

  • 79K10 - O RING 10
  • Use with poppet couplers

4 6534346

  • 6534346 - HOSE
  • inlet

5 6534347

  • 6534347 - HOSE
  • outlet

6 731794

  • 731794 - CONNECTR
  • W/Ref. 2

7 17KB1012

  • 17KB1012 - FITTING
  • HYD ELBOW
  • W/Ref. 2 - used with flush face couplers - Was 1302104B

8 17K7

  • 17K7 - ELBOW
  • W/Ref. 2 - used with poppet couplers

9 7246790

  • 7246790 - COUPLER FF FEM 1/2
  • - straight - Was 6672960

10 6598758

  • 6598758 - COUPLER FF FEMALE
  • straight

11 48K16

  • 48K16 - O RING 10
  • Use with poppet coupler

12 7246790EF

  • 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD

13 6598757

  • 6598757 - COUPLER
  • POPPET MALE
  • straight

14 7246777

  • 7246777 - COUPLER
  • FF MALE
  • - straight - Was 6674688

15 7246777EF

  • 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE

16 84G3110

  • 84G3110 - SCREW

17 6532860

  • 6532860 - PLATE
  • WEAR

18 6532861

  • 6532861 - SHIM

19 6533319

  • 6533319 - BAR
  • WEAR

20 743108

  • 743108 - FITTING
  • W/Ref. 15

21 79K8

  • 79K8 - O RING 10

22 6640724

  • 6640724 - HOSE

23 6533046

  • 6533046 - HOSE

24 6532869

  • 6532869 - PIN

25 6569312

  • 6569312 - ORIFICE
  • 2
  • 73 mm (0.108") dia. - 10
  • 67 mm (0.42") OD - Was 6592824

26 6592824

  • 6592824 - ORIFICE
  • 2
  • 73 mm (0.108") dia. - 14 mm (0.55") OD

27 6528927

  • 6528927 - WASHER

28 6534677

  • 6534677 - TUBE

29 6534678

  • 6534678 - TUBE

30 84G3720

  • 84G3720 - SCREW THD ROLLING TT

31 55D6

  • 55D6 - NUT

32 97K8

  • 97K8 - O-RING
  • for flared end

33 11K6

  • 11K6 - UNION
  • flat boss face

34 77F5

  • 77F5 - FITTING
  • W/Ref. 36 - flat boss face

35 6649389

  • 6649389 - HOSE
  • CVR BULK/FT
  • bulk - sold per foot - for Ref. 17 hose

36 6610510

  • 6610510 - STRAP
  • TIE 10
  • Was 1715312B

37 97K10

  • 97K10 - O-RING 10
  • for flare end

38 14K7

  • 14K7 - TEE

39 97K10

  • 97K10 - O-RING 10
  • for flare end

40 15KB1010

  • 15KB1010 - FITTING
  • HYD CONNECTOR
  • flat boss face

41 15K7

  • 15K7 - FITTING
  • flat boss face

42 97K10

  • 97K10 - O-RING 10
  • for flare end

43 11K7

  • 11K7 - ADAPTER
  • flat boss face

44 79K6

  • 79K6 - O RING 10
  • flat boss face

45 97K6

  • 97K6 - O-RING
  • tapered boss face
