LOCK 6532607 (2)

LOCK 6532607 (2)

LOCK 6532607 (2)

1 6532607

  • 6532607 - LOCK

2 6610077

  • 6610077 - SPRING

3 7D6

  • 7D6 - NUT

4 17C620

  • 17C620 - BOLT

5 17C816

  • 17C816 - BOLT

6 6675364

  • 6675364 - HANDLE ASSEMBLY
  • W/switch

7 8D6

  • 8D6 - NUT HEX JAM

8 6586081

  • 6586081 - CONNECTOR

9 25E16

  • 25E16 - WASHER FLAT PLAIN

10 17C556

  • 17C556 - BOLT

11 25E21

  • 25E21 - WASHER FLAT PLAIN

12 61D8

  • 61D8 - NUT 5

13 85D8

  • 85D8 - NUT PRETRQ HEX LOCK

14 6515888

  • 6515888 - KNOB

15 6532153

  • 6532153 - ROD

16 6806874

  • 6806874 - LEVER
  • L.H.

17 6532160

  • 6532160 - SHAFT

18 227395

  • 227395 - PIN
  • CLEVIS

19 1F208

  • 1F208 - PIN

20 6532193

  • 6532193 - ROD

21 6532192

  • 6532192 - LINK

22 6659298

  • 6659298 - PIN

23 38C816

  • 38C816 - BOLT

24 6651231

  • 6651231 - ROD END

25 62D5

  • 62D5 - NUT

26 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

27 6587704

  • 6587704 - BELLCRANK
  • R.H. - 1/2'' ID

28 1315207

  • 1315207 - RING RETAINING

29 7D8

  • 7D8 - NUT 5

30 6700170

  • 6700170 - WASHER
  • Plastic

31 6808259

  • 6808259 - DECAL
  • CONTROL
  • Controls

32 6532698

  • 6532698 - DECAL
  • Mounting

33 17C628

  • 17C628 - BOLT

34 61D5

  • 61D5 - NUT HEX FINISHED GR5

35 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

36 5DM14

  • 5DM14 - NUT
  • LOCK
