VALVE, SECTION 6519601

VALVE, SECTION 6519601

VALVE, SECTION 6519601

1 6519601

  • 6519601 - VALVE
  • SECTION
  • bucket & dipp. - Ref. 2-25

2 947744

  • 947744 - DUSTSEAL
  • dust

3 947752

  • 947752 - RETAINER
  • dust cover

4 947746

  • 947746 - WASHER

5 6632473

  • 6632473 - PLUG
  • Was 947754B

6 1550482

  • 1550482 - SPRING

7 947718

  • 947718 - PLUNGER
  • lift check

8 6519632

  • 6519632 - PLUG

9 947737

  • 947737 - SPRING

10 947717

  • 947717 - PLUNGER
  • lift check

11 947745

  • 947745 - RETAINER

12 947749

  • 947749 - WASHER

13 947738

  • 947738 - SPRING

14 947750

  • 947750 - SCREW

15 947710

  • 947710 - CAP ASSY

16 6631988

  • 6631988 - BOLT

17 948308

  • 948308 - KIT
  • W/Ref. 6
  • 8
  • 9
  • 11
  • 15 & 19
