TEETH 6505114

TEETH 6505114

TEETH 6505114

1 6505114

  • 6505114 - TEETH
  • grapple

2 10H35

  • 10H35 - FTG GREASE STRAIGHT

3 6505211

  • 6505211 - PIN
  • HINGE

4 6598756

  • 6598756 - COUPLER
  • Female - poppet

5 7246790

  • 7246790 - COUPLER FF FEM 1/2
  • - straight - Was 6672960

6 7246790EF

  • 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD

7 25K40026

  • 25K40026 - O RING 10
  • Use with poppet coupler

8 6505209

  • 6505209 - PIN
  • HINGE

9 6505115

  • 6505115 - FRAME

10 89F5

  • 89F5 - CONNECTR

11 83F5

  • 83F5 - ELBOW

12 6501435

  • 6501435 - HOSE

13 10K6

  • 10K6 - FITTING
  • union

14 6502426

  • 6502426 - CLAMP
  • Double

15 6505210

  • 6505210 - PIN
  • HINGE

16 61D6

  • 61D6 - NUT HEX FINISHED GR5

17 6501966

  • 6501966 - HOSE

18 6598755

  • 6598755 - COUPLER
  • Male - poppet

19 7246777

  • 7246777 - COUPLER
  • FF MALE
  • - Was 6674688

20 7246777EF

  • 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE

21 6513709

  • 6513709 - CAP AND PLUG
  • assy.- Rubber

22 6515168

  • 6515168 - CAP
  • Steel

23 6515167

  • 6515167 - CAP
  • Steel

24 6669284

  • 6669284 - ADAPTER
  • COUPLER
  • Use with flush face couplers
