BOLT 29G412
1 29G412
- 29G412 - BOLT
2 54K20002
- 54K20002 - O'RING 10
3 6587763
- 6587763 - BOOT
4 6589564
- 6589564 - RETAINER
- flat
5 1K127
- 1K127 - O-RING 10
- Was 93K127
6 6666582
- 6666582 - SPOOL BOM
- lift - #1 or red - SEE NOTE
7 6666583
- 6666583 - SPOOL BOM
- lift - #2 or green - SEE NOTE
8 6666584
- 6666584 - SPOOL BOM
- lift - #3 or black - SEE NOTE
9 6666585
- 6666585 - SPOOL
- TILT
- tilt - #1 or red - SEE NOTE
10 6666586
- 6666586 - SPOOL
- TILT
- tilt - #2 or green - SEE NOTE
11 6666587
- 6666587 - SPOOL
- TILT
- tilt - #3 or black - SEE NOTE
12 6592119
- 6592119 - SPOOL
- auxiliary - SEE NOTE
13 6592115
- 6592115 - SEAT
14 6592117
- 6592117 - SPRING
- LOAD CHECK
15 79K8
- 79K8 - O RING 10
16 6592116
- 6592116 - NUT
- load check
17 6683274
- 6683274 - SEAL
- SPOOL 10
- - Was 7031367
18 6589565
- 6589565 - SEAL
- seal
19 6660644
- 6660644 - CAP
20 6662848
- 6662848 - CAP
21 6595663
- 6595663 - BUSHING
22 6592720
- 6592720 - PLUG
- W/Ref. 23-25
23 6587304
- 6587304 - ORIFICE
24 6587315
- 6587315 - RESTRICTR
25 79K10
- 79K10 - O RING 10
26 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
27 58K014
- 58K014 - O-RING 10
28 29G416
- 29G416 - BOLT
29 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
30 30G416
- 30G416 - BOLT
31 6592109
- 6592109 - ADAPTER
32 6592100
- 6592100 - COLLAR
33 6587580
- 6587580 - SPRING
34 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
35 799119
- 799119 - RING
36 6592098
- 6592098 - WASHER
37 6589226
- 6589226 - COVER
- END
- 0.63" flange
38 6592096
- 6592096 - SLEEVE
- lift
39 6587575
- 6587575 - ADAPTER
40 6592107
- 6592107 - SPRING
- DETENT 5
41 6592105
- 6592105 - BALL 5
42 6586918
- 6586918 - SCREW
- DETENT
43 6596807
- 6596807 - PLUG
- plastic - 0.46" long
44 6593349
- 6593349 - SLEEVE
- aux.
45 6676195
- 6676195 - VALVE
- RELIEF
- For 440 only - Was 6641434
46 6659574
- 6659574 - SEAL KIT
47 47K7
- 47K7 - PLUG
- W/Ref. 23
48 6632279
- 6632279 - KIT
- SEAL
49 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 23-25 - Was 6586461
50 6816251
- 6816251 - KIT
- SEAL
- - Ref. 2 - 4
- 6
- 13
- 15
- 23-25 & 41 - Was 6816717
51 6816250
- 6816250 - KIT
- SEAL
- Ref. 2 - 4
- 6
- 15 & 41 - For one spool - Was 6803605
