Bobcat
/
540
/
LEVER 6512209 (1)

LEVER 6512209 (1)

LEVER 6512209 (1)

1 6512209

  • 6512209 - LEVER
  • throttle

2 6512207

  • 6512207 - HOUSING
  • breather - W/Breather

3 6512208

  • 6512208 - GASKET

4 6517077

  • 6517077 - CONNECTOR

5 6630913

  • 6630913 - TUBELINE

6 6512204

  • 6512204 - GASKET
  • governor

7 1311214

  • 1311214 - ROD

8 14D10

  • 14D10 - NUT HEX MACH SCREW

9 6515194

  • 6515194 - JOINT
  • rod end - Was 1301359B

10 6513715

  • 6513715 - WASHER
  • Use to plug hole when Ref. 6
  • 8 & 9 are removed

11 6513716

  • 6513716 - PLUG
  • Use to plug hole when Ref. 6
  • 8 & 9 are removed

12 6513717

  • 6513717 - BOLT
  • Use to plug hole when Ref. 6
  • 8 & 9 are removed

13 6512173

  • 6512173 - HOSE
