HOUSING, LAMP 6558142 (1)

HOUSING, LAMP 6558142 (1)

HOUSING, LAMP 6558142 (1)

1 6558142

  • 6558142 - HOUSING
  • LAMP

2 6557486

  • 6557486 - LAMP

3 6564837

  • 6564837 - HARNESS

4 6665606

  • 6665606 - SWITCH
  • IGN

5 6693241

  • 6693241 - KEY (2)
  • ignition - single key W/O ring

6 6512809

  • 6512809 - KEYSET 10
  • For NLA/6519592 switch

7 6513469

  • 6513469 - HOLDER
  • FUSE

8 6513468

  • 6513468 - #168 BULB

9 6558242

  • 6558242 - HOLDER

10 898731

  • 898731 - LAMP

11 6564907

  • 6564907 - SOCKET ASSY LAMP

12 6512808

  • 6512808 - SWITCH-LT

13 6564787

  • 6564787 - PANEL

14 6557493

  • 6557493 - GROMMET

15 6664886

  • 6664886 - METER HOUR
  • Was 6631657

16 6669664

  • 6669664 - GAUGE VOLT
  • W/O clamp

17 30H45

  • 30H45 - CLIP
  • Was 30H000041B

18 6563740

  • 6563740 - LIGHT
  • SEALED BEAM

19 6669665

  • 6669665 - GAUGE FUEL
  • W/O clamp

20 61D5

  • 61D5 - NUT HEX FINISHED GR5

21 10C512

  • 10C512 - BOLT SQ NECK RND HD
  • Was 6553808

22 17C572

  • 17C572 - BOLT

23 83D5

  • 83D5 - LKNUT HEX FLG GR8

24 85G608

  • 85G608 - SCREW

25 12D6

  • 12D6 - NUT HEX MACH SCREW

26 6598721

  • 6598721 - NUT
  • for NLA/6519592 Switch

27 6674202

  • 6674202 - NUT
  • for 6665606 Switch

28 12E6

  • 12E6 - WASHER

29 6560699

  • 6560699 - LENS
  • Was 6564785

30 6514643

  • 6514643 - GASKET

31 6514642

  • 6514642 - CAP 5

32 6514742

  • 6514742 - RIVET

33 6631649

  • 6631649 - TEMPGAUGE
  • engine temp.

34 6560117

  • 6560117 - WIRE

35 742876

  • 742876 - GROMMET

36 6599781

  • 6599781 - KNOB
  • light switch

37 895771

  • 895771 - #161 BULB

38 6599696

  • 6599696 - SOCK AND BULB
  • Assy.

39 1319451

  • 1319451 - FUSE 5

40 6724282

  • 6724282 - KIT
  • SWITCH IGN
  • switch - Ref. 4 & 5
