Angle Broom
/
BOLT 17C724

BOLT 17C724

BOLT 17C724

1 17C724

  • 17C724 - BOLT

2 6531100

  • 6531100 - BEARING
  • W/Ref. 6
  • 9 & 10 - Was 6518258

3 6508332

  • 6508332 - CORE
  • brush

4 4E5

  • 4E5 - WASHER

5 61D5

  • 61D5 - NUT HEX FINISHED GR5

6 61D7

  • 61D7 - NUT

7 4E7

  • 4E7 - WASHER

8 6515095

  • 6515095 - COLLAR
  • locking - W/Ref. 6

9 6518259

  • 6518259 - BEARING

10 6508602

  • 6508602 - SPROCKET

11 6508596

  • 6508596 - BRISTLE
  • wire

12 6508338

  • 6508338 - BRISTLE
  • polypropylene

13 17C520

  • 17C520 - BOLT 5

14 6508460

  • 6508460 - STRAP
