SHIELD 6714195 (1)
1 6714195
- 6714195 - SHIELD
2 57D6
- 57D6 - NUT HEX FLNG GR8
- flanged hex - Use W/Ref. 4 (37C620 bolt) 31
- 75 mm (1.25") long
3 6705232
- 6705232 - WASHER
4 37C620
- 37C620 - BOLT CARRIAGE
- 31
- 75 mm (1.25") long - Use W/Ref. 2 (57D6 nut)
5 7268603
- 7268603 - BEARING
- FLANGE
6 35C628
- 35C628 - BOLT
7 6714201
- 6714201 - SHAFT
- BROOM
- 2134 mm (84") broom
8 7130505
- 7130505 - SHAFT
- 2134 mm (84") broom
9 6714171
- 6714171 - PLATE
10 35C616
- 35C616 - SCREW FLGD HEX CAP
11 7299066EF
- 7299066EF - BRISTLE
- POLY/WIRE 32 EF BLACK CONV
- EF - polypropylene
12 6672506
- 6672506 - BRUSH
- POLY CONVOLUTED 32"
- factory option - polypropylene
13 6988135
- 6988135 - WAFER
- 32' EARTHFORCE CONVOLUTED
14 7241796
- 7241796 - BRISTLE
- POLY HD 32" CONVOLUTED
- polypropylene
15 6989022
- 6989022 - BRISTLE
- WIRE 32" CONVOLUTED
- broom should not use more than 1/2 steel brushes
16 6989143
- 6989143 - BRISTLE
- POLY/WIRE 32" CONVOLUTED
- polypropylene
17 6672506EF
- 6672506EF - BRISTLE
- EF BLACK CONV 32
- EF
18 7241795
- 7241795 - BRISTLE
- POLY HD 32" FLAT
- polypropylene - installed on ends of brush assembly
19 6988134
- 6988134 - WAFER
- 32' EARTHFORCE FLAT
- installed on ends of brush assembly
20 6672504
- 6672504 - BRUSH
- POLY FLAT 32"
- factory option - polypropylene - installed on ends of brush assembly
21 6905026
- 6905026 - WASHER
22 35C820
- 35C820 - BOLT
- Was 35C000816B
23 7115620
- 7115620 - DECAL
- logo
24 7121368
- 7121368 - SPACER 4
- service only - see Serviceletter 5181 - 5 March 2007
