KIT, DEFLECTOR ANGLE BROOM 7222284 (1)

KIT, DEFLECTOR ANGLE BROOM 7222284 (1)

KIT, DEFLECTOR ANGLE BROOM 7222284 (1)

1 7222284

  • 7222284 - KIT
  • DEFLECTOR ANGLE BROOM
  • Ref. 2-5

2 7222283

  • 7222283 - KIT
  • DEFLECTOR ANGLE BROOM
  • Ref. 2-5

3 31C512

  • 31C512 - BOLT

4 85D5

  • 85D5 - NUT PRETRQ HEX LOCK

5 7203377

  • 7203377 - DEFLECTOR
  • FRONT
  • Use W/Ref. 1 (7222284 kit)

6 7221368

  • 7221368 - DEFLECTOR
  • FRONT
  • Use W/Ref. 1 (7222283 kit)

7 6990469

  • 6990469 - INSTRUCTIONS
